General Details

Powered by the latest Intel® Xeon® 6 processors, supporting configurations with up to 144 cores, delivering exceptional performance for compute-intensive workloads.
Supports up to 16 DDR5 DIMM slots, allowing a maximum memory capacity of 4 TB, with speeds up to 6400 MT/s, enhancing memory bandwidth and performance.
Equipped with advanced PCIe Gen5 expansion capabilities, including up to 6 x16 PCIe Gen5 slots and 2 x16 OCP 3.0 slots, facilitating high-speed data transfer and network connectivity.
Integrated with HPE Integrated Lights-Out 7 (iLO 7) server management software, providing secure, remote management and monitoring of the server infrastructure.
Offers hot-pluggable, high-availability RAID M.2 boot options, ensuring reliable and efficient system boot processes.
Supports optional direct liquid cooling solutions for high-wattage processors, enhancing thermal efficiency and system reliability.

Features

Specs

Documents

Request Quote

HPE ProLiant DL340 Gen12 Key Features

Key Features

Simplified Cloud Operations: Easy, Self-Service, and Automated

The HPE ProLiant DL340 Gen12 server is engineered for hybrid environments, streamlining compute management from edge to cloud with a user-friendly cloud operational approach.

Empower your team to transition from reactive to proactive operations using a self-service console that offers global visibility and insights.

Automate deployment tasks for increased efficiency and instant scalability, simplifying support and lifecycle management while reducing maintenance windows.

These capabilities are integrated into every HPE ProLiant Gen12 server, whether purchased outright or accessed through HPE GreenLake as your computing and storage needs expand.

Streamline and secure server management across the entire computing landscape, from edge to cloud, with HPE GreenLake for Compute Ops Management. This as-a-service computing management solution offers enhanced simplicity, agility, and speed on a global scale.

Trusted Security: Unwavering, Foundational, and Safeguarded

The HPE ProLiant DL340 Gen12 server integrates HPE's silicon root of trust and Intel® Xeon® 6 processors with hardware- and software-assisted security features, such as Intel® Software Guard Extensions (SGX) and Trusted Domain Extensions (TDX), to oversee secure boot, memory encryption, and secure virtualization.

Utilizing the silicon root of trust, HPE ProLiant Gen12 servers establish an immutable identifier for firmware, ensuring precise matching before server boot-up. This fortifies containment of malicious code and safeguards the server's health.

HPE ProLiant Gen12 servers maintain continuous protection for servers at the edge by swiftly identifying security breaches, even preventing boot-up if malicious code is detected, with default IDevID certificates.

Automated recovery mechanisms in HPE ProLiant Gen12 servers swiftly address security incidents, restoring validated firmware and facilitating the recovery of the operating system, applications, and data connections to swiftly resume normal operations.

From hardware to software, from factory assembly to cloud deployment, HPE ProLiant Gen12 embodies a core security philosophy, continuously evolving to counter evolving threats with an unwavering dedication to security enhancements ingrained in our DNA.

Tailored Performance for Your Workloads: Enhanced, Flexible, and Streamlined

The HPE ProLiant DL340 Gen12 server is optimized for cloud-native, containerized, and scale-out environments, as well as other workloads requiring high core density and efficient multi-threading.

Harness substantial computing power. Powered by Intel® Xeon® 6 processors supporting up to 144 cores, the HPE ProLiant DL340 Gen12 server delivers exceptional performance for compute-intensive workloads.

Experience advanced data transfer rates and elevated network speeds facilitated by the PCIe Gen5 serial expansion bus, with up to 6 x16 PCIe Gen5 slots and front or rear OCP NIC or controller add-in card slots, enhancing I/O throughput while minimizing latency.

Boost memory bandwidth and efficiency, while reducing power consumption, thanks to 16 DIMM slots supporting up to 4 TB of DDR5 memory.

Gain valuable insights into server performance in real-time, coupled with recommendations for optimizing BIOS settings to adapt to evolving business requirements.

HPE ProLiant DL340 Gen12 Request Quote

Contact Sales:

New HPE ProLiant DL340 Gen12

HPE ProLiant DL340 Gen12 Specifications

Processor Type: Intel®

Processor Family: Intel® Xeon® 6 processors

Processor Cores Available: 8 to 144 cores, depending on processor

Processor Cache: 48 MB to 336 MB L3, depending on processor

Maximum Memory: 4.0 TB, when populated with 256 GB DDR5 memory modules

Memory Slots: 16 DIMM slots

Memory Type: DDR5

Memory Protection Features: Advanced ECC Memory
Online Spare Memory
Mirrored Memory

Drive Support: Up to 12 LFF SAS/SATA HDDs or SSDs
Up to 24 SFF SAS/SATA/NVMe drives
Up to 36 EDSFF E3.S drives
Optional embedded M.2 Boot SSDs
Optional RAID 1 NVMe M.2 Boot device

Infrastructure Management: HPE Integrated Lights-Out 7 (iLO 7) with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced (requires license)

System Fan Features: Standard Fan Kit or High-Performance Fan Kit, depending on model

Expansion Slots: Up to 6 PCIe Gen5 slots and 2 OCP 3.0 slots, for detailed descriptions please refer to the QuickSpecs

Network Controller: Wide range of speeds, cabling, chipsets, and form factors (PCIe stand-up adapter and OCP 3.0). Please refer to the QuickSpecs for network card choices

Storage Controller: Included - Embedded SATA controller (AHCI or Intel SATA software RAID controller)
Optional - HPE Smart Array Gen11 Storage Controllers supporting various protocols, port counts, array utilities, and form factors (PCIe stand-up adapter and OCP 3.0). Please refer to the QuickSpecs for storage controller selections

Warranty: Server warranty includes 3-years parts, 3-years labor, 3-years on-site support with next business day response. Additional information regarding worldwide limited warranty and technical support is available at: www.hpe.com/services/support. Additional Hewlett Packard Enterprise support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to www.hpe.com/services/support.

Processor Number: 1
