HPE ProLiant DL320 Gen12 Key Features
Key Features
Simplified Cloud Operations: Easy, Self-Service, and Automated
The HPE ProLiant DL320 Gen12 server is engineered for hybrid
environments, streamlining compute management from edge to cloud with a user-friendly cloud
operational approach.
Empower your team to transition from reactive to proactive operations
using a self-service console that offers global visibility and insights.
Automate deployment tasks for increased efficiency and instant
scalability, simplifying support and lifecycle management while reducing maintenance
windows.
These capabilities are integrated into every HPE ProLiant Gen12 server,
whether purchased outright or accessed through HPE GreenLake as your computing and storage
needs expand.
Streamline and secure server management across the entire computing
landscape, from edge to cloud, with HPE GreenLake for Compute Ops Management. This
as-a-service computing management solution offers enhanced simplicity, agility, and speed on
a global scale.
Trusted Security: Unwavering, Foundational, and Safeguarded
The HPE ProLiant DL320 Gen12 server integrates HPE's silicon root of
trust and Intel® Xeon® 6 processors with hardware- and software-assisted security features,
such as Intel® Software Guard Extensions (SGX) and Trusted Domain Extensions (TDX), to
oversee secure boot, memory encryption, and secure virtualization.
Utilizing the silicon root of trust, HPE ProLiant Gen12 servers establish
an immutable identifier for firmware, ensuring precise matching before server boot-up. This
fortifies containment of malicious code and safeguards the server's health.
HPE ProLiant Gen12 servers maintain continuous protection for servers at
the edge by swiftly identifying security breaches, even preventing boot-up if malicious code
is detected, with default IDevID certificates.
Automated recovery mechanisms in HPE ProLiant Gen12 servers swiftly
address security incidents, restoring validated firmware and facilitating the recovery of
the operating system, applications, and data connections to swiftly resume normal
operations.
From hardware to software, from factory assembly to cloud deployment, HPE
ProLiant Gen12 embodies a core security philosophy, continuously evolving to counter
evolving threats with an unwavering dedication to security enhancements ingrained in our
DNA.
Tailored Performance for Your Workloads: Enhanced, Flexible, and
Streamlined
The HPE ProLiant DL320 Gen12 server is optimized for cloud-native,
containerized, and scale-out environments, as well as other workloads requiring high core
density and efficient multi-threading.
Harness substantial computing power. Powered by Intel® Xeon® 6 processors
supporting up to 144 cores, the HPE ProLiant DL320 Gen12 server delivers exceptional
performance for compute-intensive workloads.
Experience advanced data transfer rates and elevated network speeds
facilitated by the PCIe Gen5 serial expansion bus, with up to 2 x16 PCIe Gen5 slots and
front or rear OCP NIC or controller add-in card slots, enhancing I/O throughput while
minimizing latency.
Boost memory bandwidth and efficiency, while reducing power consumption,
thanks to 16 DIMM slots supporting up to 4 TB of DDR5 memory.
Gain valuable insights into server performance in real-time, coupled with
recommendations for optimizing BIOS settings to adapt to evolving business requirements.
HPE ProLiant DL320 Gen12 Request Quote
Contact Sales:
HPE ProLiant DL320 Gen12 Specifications
Processor Type:
Intel®
Processor Family:
Intel® Xeon® 6 processors
Processor cores available:
8 to 144 cores, depending on processor
Processor cache:
48 to 336 MB L3, depending on processor
Maximum memory:
4.0 TB, when populated with 256 GB DDR5 Memory
Memory Slots:
16 DIMM slots
Memory type:
HPE DDR5 Smart Memory
Memory protection features:
Advanced ECC
Adaptive Double DRAM Device Correction (ADDDC)
Memory Mirroring
Adaptive Double DRAM Device Correction (ADDDC)
Memory Mirroring
Drive supported:
Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SSDs, depending on model.
Up to 12 LFF SAS/SATA HDDs or SSDs, depending on model.
Up to 20 EDSFF E3.S 1T, depending on model.
Optional RAID 1 NVMe M.2 Boot device (Internal or external accessible from rear wall or front cage with 2x NVMe M.2 incorporated, depending on model).
Up to 12 LFF SAS/SATA HDDs or SSDs, depending on model.
Up to 20 EDSFF E3.S 1T, depending on model.
Optional RAID 1 NVMe M.2 Boot device (Internal or external accessible from rear wall or front cage with 2x NVMe M.2 incorporated, depending on model).
Infrastructure management:
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (subscription included)
System fan features:
Standard Fan Kit or High Performance Fan Kit, depending on model
Expansion Slots:
Up to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor, for detailed descriptions reference the QuickSpecs
Network Controller:
Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0). Please refer to the QuickSpecs for network card choices
Storage controller:
Optional - HPE MR216i-o, MR216i-p, MR408i-o, MR408i-p, MR416i-o, and MR416i-p storage controllers. Please refer to the QuickSpecs for storage controller selection
Warranty:
Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://www.hpe.com/support/ProLiantServers-Warranties. Additional HPE support and service coverage, to supplement the product warranty, is available at: https://www.hpe.com/support.
Processor number:
1
