General Details

Empower your infrastructure with the Dell PowerEdge R6715, designed for scale-out virtualization, cloud-hosted microservices, and virtual desktop infrastructure (VDI). Featuring support for one 5th Generation AMD EPYC™ 9005 Series processor, this 1U single-socket server delivers uncompromised multi-core performance and exceptional architecture consolidation values.
The PowerEdge R6715 Rack Server excels in single-socket efficiency and space savings, supporting up to 160 CPU cores and a flexible storage layout with NVMe, SAS, SATA, or high-density EDSFF options. With up to 3 PCIe Gen5 slots, it’s engineered for modern web tiers, intensive container environments, and cost-sensitive virtualization infrastructure where minimizing per-socket software licensing fees is paramount.
With 24 DIMM slots capable of housing up to 6TB of ultra-fast DDR5 ECC Registered memory, the R6715 ensures high memory bandwidth and massive active workspace capacity, making it ideal for handling dense container instances and thousands of concurrent virtual desktops.
Built for reliability and manageability, the R6715 includes hot-plug redundant power supplies, advanced hardware-enforced protection via AMD Infinity Guard, and Dell’s iDRAC10 with Lifecycle Controller for seamless remote monitoring and lifecycle automation.

Features

Specs

Documents

Request Quote

Dell PowerEdge R6715 Key Features

Key Features

Streamlined data center orchestration for scale-out AMD architectures

The Dell EMC OpenManage systems management portfolio provides centralized and remote server management capabilities, allowing IT teams to automate updates, monitor performance, and reduce human error. Integration with Redfish APIs, telemetry streaming, and tools like iDRAC10 make it easy to scale operations across large deployments.

With iDRAC Direct and Quick Sync 2 wireless module, administrators can configure, deploy, and manage PowerEdge R6715 servers without disrupting ongoing workloads—saving time and reducing complexity.

OpenManage Enterprise, SupportAssist, and Update Manager simplify the ongoing maintenance lifecycle, offering proactive alerts, inventory tracking, and patch automation from a unified interface.

Breakthrough single-socket efficiency

The PowerEdge R6715 delivers high core counts and memory bandwidth with a single 5th Generation AMD EPYC™ 9005 Series processor—up to 160 cores—making it ideal for cost-sensitive, high-performance workloads such as scale-out virtualization, VDI, or container frameworks.

With support for PCIe Gen5, up to 3 single-width GPU accelerators, and dense NVMe storage, this 1U server offers performance comparable to legacy dual-socket setups with lower power consumption and licensing costs.

The server supports up to 6TB of DDR5 ECC memory and a range of storage options including 10 x 2.5" NVMe, SAS, or SATA drives, enabling flexible deployment from edge to data center.

Robust virtualization protection via AMD Infinity Guard security

The PowerEdge R6715 includes a silicon root of trust, secure boot, and system lockdown features to ensure firmware integrity and prevent unauthorized configuration changes.

AMD Secure Memory Encryption (SME) and Secure Encrypted Virtualization (SEV) protect data-in-use and in-memory workloads from internal and external threats.

Dell PowerEdge R6715 Request Quote

Contact Sales:

Dell PowerEdge R6715

Dell PowerEdge R6715 Specifications

Processor 1 x 5th Generation AMD EPYC™ 9005 Series processor, up to 160 cores

Operating System Microsoft Windows Server with Hyper-V
VMware ESXi
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Canonical Ubuntu Server LTS

Memory 24 DDR5 DIMM slots, up to 6TB RDIMM max
Supports registered ECC DDR5 DIMMs only, up to 5200 MT/s

Storage Front bays:
Up to 10 x 2.5" SAS/SATA/NVMe
Up to 4 x 3.5" SAS/SATA
Up to 20 x EDSFF E3.S Gen5 NVMe drives

Rear bays:
Up to 2 x EDSFF E3.S drives

Storage Controllers PERC H365i, H965i, H975i
Internal Boot: BOSS-N1 DC-MHS module with 2 x M.2 NVMe SSDs
External HBAs: HBA465e

GPU Support Up to 3 x 75W single-width GPUs

Expansion Up to 5 x PCIe Gen5 slots (x16 connectors)

Security AMD SME/SEV
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 2.0 FIPS certified

Management iDRAC10 with Lifecycle Controller
OpenManage Enterprise & Mobile

Networking 1 x Dedicated iDRAC Ethernet port
2 x OCP NIC 3.0 slot
Supports 1/10/25/400 GbE

Front Ports 1 x USB 2.0
1 x USB 2.0 Type-C (HOST/BMC Direct)
1 x VGA

Rear Ports 1 x USB 3.1 Type-A
1 x USB 3.1 Type-A
1 x VGA

Power Supplies Dual hot-plug redundant PSUs
800W, 1100W Platinum/Titanium, or up to 1800W Titanium efficiency options

Form Factor 1U rack server

Dimensions Height: 42.8 mm (1.68 in)
Width: 482 mm (18.98 in)
Depth: 815.14 mm (32.09 in) without bezel
Weight: varies by configuration

Dell PowerEdge R6715 Documents

QuickSpecs

QuickSpecs (PDF)

QuickSpecs (HTML)

Support & Downloads

Dell R6715 Overview

Dell R6715 Software

Extra Links

Technical Sheet

Quick Reference Guide

ServerMonkey Support

TekShield

Server Docs

Dell R6715 Docs

Related Server Products

Dell Servers

Dell 17th Gen Servers

Dell PowerEdge R6715 Server

The Dell PowerEdge R6715 is a highly efficient, single-socket 1U rack server built around the advanced AMD EPYC™ 5th Generation (Turin) processor line. Purpose-built to optimize your computing infrastructure, the R6715 packs massive core architectures and high-speed DDR5 memory channels into a dense 1U footprint. This server is the definitive choice for businesses aiming to optimize single-socket software licensing costs across scale-out cloud environments, VDI deployments, and virtualization layers.
