Dell PowerEdge R670 Key Features
Key Features
Enterprise-scale automation for dense multi-tenant deployments
The Dell EMC OpenManage systems management portfolio provides centralized and remote server management capabilities, allowing IT teams to automate updates, monitor performance, and reduce human error. Integration with Redfish APIs, telemetry streaming, and tools like iDRAC10 make it easy to scale operations across large deployments.
With iDRAC Direct and Quick Sync 2 wireless module, administrators can configure, deploy, and manage PowerEdge R670 servers without disrupting ongoing workloads—saving time and reducing complexity.
OpenManage Enterprise, SupportAssist, and Update Manager simplify the ongoing maintenance lifecycle, offering proactive alerts, inventory tracking, and patch automation from a unified interface.
Exceptional performance and efficiency in a dual-socket design
The PowerEdge R670 delivers high core counts and memory bandwidth with up to two Intel® Xeon® 6 processors—up to 288 total E-cores or 172 total P-cores—making it ideal for space-constrained, high-performance workloads such as dense virtualization, corporate databases, or web microservices.
With support for PCIe Gen5, up to 2 single-width GPU accelerators, and dense NVMe storage, this 1U server offers performance comparable to bulkier infrastructure configurations with optimized power consumption and licensing costs.
The server supports up to 2TB of DDR5 ECC memory and a range of storage options including 20 x EDSFF E3.S Gen5 NVMe, SAS, or SATA drives, enabling flexible deployment from edge to data center.
Advanced cyber-resiliency with Intel SGX and confidential computing
The PowerEdge R670 includes a silicon root of trust, secure boot, and system lockdown features to ensure firmware integrity and prevent unauthorized configuration changes.
Intel® Total Memory Encryption (TME) and Software Guard Extensions (SGX) protect data-in-use and in-memory workloads from internal and external threats.
Dell PowerEdge R670 Request Quote
Contact Sales:
Dell PowerEdge R670 Specifications
Processor
Up to 2x Intel Xeon 6 processors, up to 144 E-cores or 86 P-cores per CPU
Operating System
Microsoft Windows Server with Hyper-V
VMware ESXi
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Canonical Ubuntu Server LTS
VMware ESXi
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Canonical Ubuntu Server LTS
Memory
Up to 32 DDR5 DIMM slots, max 2TB with RDIMM
Supports registered ECC DDR5 DIMMs only, up to 6400 MT/s
Supports registered ECC DDR5 DIMMs only, up to 6400 MT/s
Storage
Front bays:
Up to 8 x 2.5" SAS/SATA/NVMe
Up to 10 x 2.5" SATA
20 x EDSFF E3.S Gen5 NVMe drives
Rear bays (optional):
Up to 2 x EDSFF E3.S NVMe drives
Up to 8 x 2.5" SAS/SATA/NVMe
Up to 10 x 2.5" SATA
20 x EDSFF E3.S Gen5 NVMe drives
Rear bays (optional):
Up to 2 x EDSFF E3.S NVMe drives
Storage Controllers
PERC H365i, H965i, H975i
Internal Boot: BOSS-N1 module with 2 x M.2 NVMe SSDs
Internal Boot: BOSS-N1 module with 2 x M.2 NVMe SSDs
GPU Support
Up to 2 x 75W single-width GPUs
Expansion
Up to 2 x 16 Gen5 PCIe slots
Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 2.0 FIPS certified
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 2.0 FIPS certified
Management
iDRAC10 with Lifecycle Controller
OpenManage Enterprise & Mobile
OpenManage Enterprise & Mobile
Networking
1 x Dedicated iDRAC Ethernet port
1 x OCP NIC 3.0 slot
Supports 1/10/25/100/400 GbE
1 x OCP NIC 3.0 slot
Supports 1/10/25/100/400 GbE
Front Ports
1 x USB 2.0
1 x USB 2.0 Type-C (HOST/BMC Direct)
1 x VGA
1 x USB 2.0 Type-C (HOST/BMC Direct)
1 x VGA
Rear Ports
1 x Dedicated BMC Ethernet port
2 x USB 3.1 Type-A
1 x VGA
2 x USB 3.1 Type-A
1 x VGA
Power Supplies
Dual hot-plug redundant PSUs
800W, 1100W, 1400W Platinum/Titanium options
800W, 1100W, 1400W Platinum/Titanium options
Form Factor
1U rack server
Dimensions
Height: 42.8 mm (1.69 in)
Width: 482 mm (18.98 in)
Depth: 815.14 mm (32.09 in) without bezel
Weight: 20.42 kg (45.02 lbs)
Width: 482 mm (18.98 in)
Depth: 815.14 mm (32.09 in) without bezel
Weight: 20.42 kg (45.02 lbs)
