Seamlessly and securely connect applications across your cloud, data center, and edge locations. Cisco routing provides intent-based networking for the WAN, LAN, and cloud. Our network routers include advanced analytics, application optimization, automated provisioning, and integrated security to deliver a complete, proven solution. Respond to business needs faster and increase IT efficiency by deploying integrated network services on demand, wherever you need them.

As a trusted Arista reseller, ServerMonkey offers the Arista 7280 Series at competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	7280DR3A-54 Series	7280DR3A-36 Series	7280PR3-24 Series	7280DR3-24 Series
Description	54 x QSFP-DD	36 x QSFP-DD	24 x OSFP	24 x QSFP-DD
Max 400G	54	36	24	24
Max 200G	108	72	48	48
Max 100G	216	144	96	96
Max 50G	348	232	192	192
Max 40G	54	36	24	24
Max 25G	348	232	192	192
Max 10G	348	232	192	192
L2/3 Throughput (FDX)	21.6 (43.2) Tbps	14.4 (28.8) Tbps	9.6 (19.2) Tbps	9.6 (19.2) Tbps
L2/3 PPS	8.1 Bpps	5.4 Bpps	4 Bpps	4 Bpps
Latency	From 3.8 usec	From 3.8 usec	From 3.8 usec	From 3.8 usec
Typical System Power Draw	933W	643W	650W	650W
Total System Buffer	24 GB	16 GB	16 GB	16 GB
Rack Units	2	2	1	1
Sync-E Support	Inband + PPS/10M/ToD	Inband + PPS/10M/ToD	-	-
MACsec/IPsec Encryption	All Ports (R3AM, R3AK)	All Ports (R3AM, R3AK)	-	-
Large Scale Routing & Policy	R3AK	R3AK	R3AK	R3AK
CloudVision	Yes	Yes	Yes	Yes
Smart System Upgrade*	Yes	Yes	Yes	Yes
ZTP	Yes	Yes	Yes	Yes
VM Tracer	Yes	Yes	Yes	Yes
AEM	Yes	Yes	Yes	Yes
VXLAN	Yes	Yes	Yes	Yes
LANZ	Yes	Yes	Yes	Yes
Accelerated sFlow	Yes	Yes	Yes	Yes
Airflow	Front to Rear
AC and DC PSU	Yes	Yes	Yes	Yes

	7280CR3A-24D12 Series	7280CR3A-48D6 Series	7280CR3-32P4 Series	7280CR3-32D4 Series
Description	24 x QSFP 12 x QSFP-DD	48 x QSFP 6 x QSFP-DD	32 x QSFP 4 x OSFP	32 x QSFP 4 x QSFP-DD
Max 400G	12	6	4	4
Max 200G	36	12	8	8
Max 100G	72	68	48	48
Max 50G	112	114	96	96
Max 40G	36	54	36	36
Max 25G	112	114	96	96
Max 10G	112	114	96	96
L2/3 Throughput (FDX)	7.2 (14.4) Tbps	7.2 (14.4) Tbps	4.8 (9.6) Tbps	4.8 (9.6) Tbps
L2/3 PPS	2.7 Bpps	2.7 Bpps	2 Bpps	2 Bpps
Latency	From 3.8 usec	From 3.8 usec	From 3.8 usec	From 3.8 usec
Typical System Power Draw	346W	388W	535W	535W
Total System Buffer	8 GB	8 GB	8 GB	8 GB
Rack Units	1	2	1	1
Sync-E Support	Inband + PPS/10M/ToD	Inband + PPS/10M/ToD	-	-
MACsec/IPsec Encryption	All Ports (R3AM, R3AK)	All Ports (R3AM, R3AK)	100G Ports (R3MK)	100G Ports (R3MK)
Large Scale Routing & Policy	R3AK	R3AK	R3AK, RMK	R3K, R3MK
CloudVision	Yes	Yes	Yes	Yes
Smart System Upgrade*	Yes	Yes	Yes	Yes
ZTP	Yes	Yes	Yes	Yes
VM Tracer	Yes	Yes	Yes	Yes
AEM	Yes	Yes	Yes	Yes
VXLAN	Yes	Yes	Yes	Yes
LANZ	Yes	Yes	Yes	Yes
Accelerated sFlow	Yes	Yes	Yes	Yes
Airflow	Front to Rear and Rear to Front
AC and DC PSU	Yes	Yes	Yes	Yes

	7280CR3-36S Series	7280CR3A-32S Series
Description	28 x QSFP 6 x QSFP200 2 x QSFP-DD	30 x QSFP100/200 2 x QSFP200/QSFP-DD
Max 400G	2	2
Max 200G	8	18
Max 100G	40	36
Max 50G	80	56
Max 40G	36	36
Max 25G	120	56
Max 10G	120	56
L2/3 Throughput (FDX)	2.4 (4.8) Tbps	3.6 (7.2) Tbps
L2/3 PPS	1 Bpps	1.35 Bpps
Latency	From 3.8 usec	From 3.8 usec
Typical System Power Draw	254W	TBD
Total System Buffer	4 GB	4 GB
Rack Units	1	1
Sync-E Support	-	Inband + PPS/10M/ToD
MACsec/IPsec Encryption	-	All Ports (R3AM, R3AK)
Large Scale Routing & Policy	R3K	R3AK
CloudVision	Yes	Yes
Smart System Upgrade*	Yes	Yes
ZTP	Yes	Yes
VM Tracer	Yes	Yes
AEM	Yes	Yes
VXLAN	Yes	Yes
LANZ	Yes	Yes
Accelerated sFlow	Yes	Yes
Airflow	Front to Rear and Rear to Front
AC and DC PSU	Yes	Yes

	7280CR3-96 Series	7280CR3A-72 Series	7280SR3A-48YC8 Series	7280SR3-48YC8 Series
Description	96 x QSFP	72 x QSFP	4 x QSFP200 4 x QSFP100 48 x SFP 10/25/50G	8 x QSFP 48 x SFP 1/10/25G
Max 400G	-	-	-	-
Max 200G	-	36	6	-
Max 100G	96	72	8	8
Max 50G	192	102	48	16
Max 40G	96	72	8	8
Max 25G	192	102	48	80
Max 10G	192	102	48	80
L2/3 Throughput (FDX)	9.6 (19.2) Tbps	7.2 (14.4) Tbps	3.6 (7.2) Tbps	2.4 (4.8) Tbps
L2/3 PPS	4 Bpps	2.7 Bpps	1.35 Bpps	1 Bpps
Latency	From 3.8 usec	From 3.8 usec	From 3.8 usec	From 3.8 usec
Typical System Power Draw	1003W	406W	TBD	154W
Total System Buffer	16 GB	8 GB	4 GB	4 GB
Rack Units	2	2	1	1
Sync-E Support	-	Inband + PPS/10M/ToD	Inband + PPS/10M/ToD	-
MACsec/IPsec Encryption	-	All Ports (R3AM, R3AK)	All Ports (R3AM, R3AK)	All Ports (MACsec only R3M)
Large Scale Routing & Policy	R3K	R3AK	R3AK	R3K
CloudVision	Yes	Yes	Yes	Yes
Smart System Upgrade*	Yes	Yes	Yes	Yes
ZTP	Yes	Yes	Yes	Yes
VM Tracer	Yes	Yes	Yes	Yes
AEM	Yes	Yes	Yes	Yes
VXLAN	Yes	Yes	Yes	Yes
LANZ	Yes	Yes	Yes	Yes
Accelerated sFlow	Yes	Yes	Yes	Yes
Airflow	Front to Rear	Front to Rear and Rear to Front
AC and DC PSU	Yes	Yes	Yes	Yes

	7280SR3-40YC6 Series	7280TR3-40C6 Series
Description	6 x QSFP 40 x SFP 1/10/25G	6 QSFP 40 x RJ45 1/10G
Max 400G	-	-
Max 200G	-	-
Max 100G	6	6
Max 50G	12	12
Max 40G	6	6
Max 25G	52	12
Max 10G	52	52
L2/3 Throughput (FDX)	800 (1600) Gbps	800 (1600) Gbps
L2/3 PPS	600 Mpps	600 Mpps
Latency	From 3.8 usec	From 3.8 usec
Typical System Power Draw	130W	186W
Total System Buffer	2 GB	2 GB
Rack Units	1	1
Sync-E Support	Inband Only (SR3E)	-
MACsec/IPsec Encryption	-	-
Large Scale Routing & Policy	-	-
CloudVision	Yes	Yes
Smart System Upgrade*	Yes	Yes
ZTP	Yes	Yes
VM Tracer	Yes	Yes
AEM	Yes	Yes
VXLAN	Yes	Yes
LANZ	Yes	Yes
Accelerated sFlow	Yes	Yes
Airflow	Front to Rear and Rear to Front
AC and DC PSU	Yes	Yes
