General Details

Empower your infrastructure with the Dell PowerEdge R770, designed for core data center workloads, heavy business systems, and AI training/inference. Featuring support for up to two Intel® Xeon® 6 processors, this 2U dual-socket server serves as the definitive enterprise baseline for multi-workload versatility and maximum operational uptime.
The PowerEdge R770 Rack Server excels in high-tier expansion and flexible storage layout, supporting up to 288 total E-cores or 172 P-cores and storage options scaling up to 24 x 2.5-inch drives or up to 40 front EDSFF E3.S Gen5 NVMe direct drives. With up to 8 PCIe Gen5 slots and support for multiple 350W double-width or 75W single-width accelerators, it’s engineered for demanding tasks like enterprise resource planning (ERP), advanced data analytics pools, and machine learning pipelines.
With 32 DIMM slots capable of housing up to 8TB of high-speed DDR5 ECC Registered memory (utilizing RDIMMs or MRDIMMs at 6400 MT/s), the R770 ensures extreme memory bandwidth and scalability, making it ideal for massive relational databases and heavy enterprise virtualization clusters.
Built for reliability and manageability, the R770 includes hot-plug redundant power supplies, smart multi-vector thermal designs, and Dell’s iDRAC10 with Lifecycle Controller for seamless remote monitoring and lifecycle automation.

Features

Specs

Documents

Request Quote

Dell PowerEdge R770 Key Features

Key Features

Centralized remote management for mission-critical enterprise arrays

The Dell EMC OpenManage systems management portfolio provides centralized and remote server management capabilities, allowing IT teams to automate updates, monitor performance, and reduce human error. Integration with Redfish APIs, telemetry streaming, and tools like iDRAC10 make it easy to scale operations across large deployments.

With iDRAC Direct and Quick Sync 2 wireless module, administrators can configure, deploy, and manage PowerEdge R770 servers without disrupting ongoing workloads—saving time and reducing complexity.

Flagship 2U performance and massive expandability with Intel Xeon 6

The PowerEdge R770 delivers high core counts and memory bandwidth with up to two Intel Xeon 6 processors—up to 288 total cores—making it ideal for business-critical, high-performance workloads such as large relational databases, machine learning, or enterprise ERP layouts.

With support for PCIe Gen5, multiple accelerator GPU expansion channels, and dense NVMe storage, this 2U server offers performance comparable to extensive multi-node setups with lower overall power requirements and footprint demands.

The server supports up to 8TB of DDR5 ECC memory and a range of storage options including 40 x EDSFF E3.S Gen5 NVMe, SAS, or SATA drives, enabling flexible deployment from edge to data center.

Full-stack data protection for complex corporate databases

The PowerEdge R770 includes a silicon root of trust, secure boot, and system lockdown features to ensure firmware integrity and prevent unauthorized configuration changes. Intel® Total Memory Encryption (TME) and Software Guard Extensions (SGX) protect data-in-use and in-memory workloads from internal and external threats.

System Erase allows for full storage and memory sanitization, ensuring secure retirement or repurposing of the server.

Dell PowerEdge R770 Request Quote

Contact Sales:

Dell PowerEdge R770

Dell PowerEdge R770 Specifications

Processor Up to 2x 6th Generation Intel Xeon processors (up to 144 E-cores or 86 P-cores per CPU)

Operating System Microsoft Windows Server
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Canonical Ubuntu Server LTS
VMware ESXi

Memory 32 DDR5 DIMM slots, up to 8TB total
Supports DDR5 RDIMM, speeds up to 6400 MT/s

Storage Front bays:
Up to 24 x 2.5" SATA/NVMe
Up to 16 x 2.5-inch SATA + 8 x NVMe
Up to 40 x EDSFF E3.S Gen5 NVMe drives

Rear bays (optional):
Up to 4 x EDSFF E3.S Gen5 NVMe drives

RAID/Controllers PERC H365i, H965i, H975i
Internal Boot: BOSS-N1 DC-MHS module with 2 x M.2 NVMe SSDs

GPU Support Up to 6 x 75W single-width GPUs
Up to 2 x 450W double-width GPUs

Expansion Up to 8 x PCIe Gen5 slots (mix of x8 and x16 connectors)

Management iDRAC10 with Lifecycle Controller
OpenManage Enterprise
Quick Sync 2 wireless module
SupportAssist, Update Manager

Security Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 2.0 FIPS certified

Networking 1 x OCP 3.0 NIC slot (up to 8 x configurations supported via Risers)
1 x Dedicated iDRAC Ethernet port

Front Ports 1 x USB 2.0
1 x USB 2.0 Type-C (HOST/BMC Direct)
1 x VGA

Rear Ports 2 x USB 3.1 Type-A
1 x Dedicated BMC Ethernet port
1 x VGA

Power Supplies Dual hot-plug redundant PSU
Options: 800W, 1100W, 1500W, 2400W, 3200W Platinum or Titanium efficiency options.

Form Factor 2U rackmount

Dimensions Height: 86.8 mm (3.41 in)
Width: 482 mm (18.97 in)
Depth:801.51 mm (31.56 in) without bezel
Weight: 28.53 kg (62.89 lbs)

Dell PowerEdge R770 Documents

QuickSpecs

QuickSpecs (PDF)

QuickSpecs (HTML)

Support & Downloads

Dell R770 Overview

Dell R770 Software

Extra Links

Technical Sheet

Quick Reference Guide

ServerMonkey Support

TekShield

Server Docs

Dell R770 Docs

Related Server Products

Dell Servers

Dell 17th Gen Servers

Dell PowerEdge R770 Server

The Dell PowerEdge R770 is the premier 2U, dual-socket enterprise rack server designed to handle core data center workloads, heavy business applications, and AI inference. Powered by dual Intel® Xeon® 6 processors, this 17th-generation powerhouse seamlessly balances flexible local storage capacity, abundant PCIe Gen5 expansion slots, and high-capacity DDR5 memory architecture. The R770 is built for corporate enterprises demanding maximum uptime, compute headroom, and multi-workload versatility.
