FS-3032D :: 1000 & 3000 Series :: Secure Ethernet Switches :: Fortinet :: Networking

Fortinet - named a leader in the 2022 Gartner Magic Quadrant for SD-WAN - offers a security-driven networking approach that defends today's highly-dynamic environments. FortiGate NGFW is designed to meet the most demanding threat protection performance requirements and is available in a variety of models, from entry-level hardware to ultra-high-end appliances. Their Secure SD-Wan systems enable the highest application experience and help monitor other FortiGate appliances. Lastly, their secure ethernet systems converge networking and security into a simple-to-manage architecture.

As a trusted Fortinet reseller, ServerMonkey offers the FortiSwitch FS-3032D at competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	FortiSwitch 1024D	FortiSwitch 1048E	FortiSwitch 3032D
Hardware Specifications
Total Network Interfaces (Proposed)	24x GE/10 GE SFP+ ports	48x GE/10 GE SFP+ ports and 4x 40 GE QSFP+ ports	32x 40 GE QSFP+ ports
10/100/1000 Service Ports	1	1	1
RJ-45 Serial Console Port	1	1	1
Form Factor	1 RU Rack-Mount Appliance	1 RU Rack-Mount Appliance	1 RU Rack-Mount Appliance
System Specifications
Switch Type	Web and CLI Managed	Web and CLI Managed	Web and CLI Managed
Switch Capacity	480 Gbps	1280 Gbps	2560 Gbps
Packets Per Second	714 Mpps	1920 Mbps	3840 Mbps
MAC Address Storage	128,000	128,000	128,000
Network Latency	< 1us	< 1us	< 1us
VLANs Supported	4k	4k	4k
Link Aggregation Group Size	up to 24	up to 24	up to 24
Total Link Aggregation Groups	24	24	16
Queues/Port	10 CoS, 5 multicast	10 CoS, 5 multicast	10 CoS, 5 multicast
Packet Buffers	9 MB	9 MB	9 MB
DRAM	2 GB	2 GB	2 GB
NAND	128 MB	128 MB	128 MB
Dimensions
Height x Width x Length (in)	1.71 x 17.26 x 18.11	1.71 x 17.26 x 18.11	1.71 x 17.26 x 18.11
Height x Width x Length (mm)	43.5 x 438.5 x 460	43.5 x 438.5 x 460	43.5 x 438.5 x 460
Weight	17.62 lbs (8 kg)	19.40 lbs (8.8 kg)	19.40 lbs (8.8 kg)
Environment
Power Required	100–240V AC, 50–60 Hz	100–240V AC, 50–60 Hz	100–240V AC, 50–60 Hz
Power Consumption (AVG)	up to 140 W	up to 215.3 W	up to 387 W
Power Supply	Dual hot swappable AC	Dual hot swappable AC	Dual hot swappable AC
Operating Temperature	32–104°F (0–40°C)	32–104°F (0–40°C)	32–104°F (0–40°C)
Storage Temperature	-13–158°F (-25–70°C)	-13–158°F (-25–70°C)	-13–158°F (-25–70°C)
Humidity	10–90% RH non-condensing	10–90% RH non-condensing	10–90% RH non-condensing
Mean Time Between Failures	> 10 years	> 10 years	> 10 years
Warranty
Fortinet Warranty	Limited lifetime warranty on all models
