Details:

Description

Category	Specifications
Max Users	SSID per Radio/Total: 8/24 Users per Radio/Total: 512/1536
802.11a	5.150–5.850 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM Modulation) Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/auto fallback
802.11b	2.4–2.5 GHz Operating Frequency Direct-Sequence Spread-Spectrum (DSSS) Modulation Rates (Mbps): 11, 5.5, 2, 1 w/auto fallback
802.11g	2.4–2.5 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM) Modulation Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/auto fallback
802.11n	2.4–2.5 GHz and 5.150–5.850 GHz Operating Frequency 802.11n Modulation HT20 High-Throughput (HT) Support for both 2.4 GHz and 5 GHz HT40 High-Throughput (HT) Support for 5 GHz A-MPDU and A-MSDU Frame Aggregation
802.11ac	5.150–5.850 GHz Operating Frequency 802.11ac Modulation (256-QAM) Rates (Mbps): MCS0 – MCS31 (6.5MBps - 600Mbps) 5G: 2x2 Multiple-In, Multiple-Out (MIMO) Radio 2.4G: 2x2 Multiple-In, Multiple-Out (MIMO) Radio Rates (Mbps): MCS0–MCS9 (6.5Mbps – 1734Mbps), NSS = 1-2 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio VHT20/VHT40/VHT80 support TxBF (Transmit Beamforming)
802.11ax	2.4–2.5 GHz & 5.150–5.850 GHz Operating Frequency 802.11ax Modulation (1024-QAM) Dual-band OFDMA Rates (Mbps): 6G: HE0-HE11 (8 Mbps – 2400 Mbps) 5G: HE0-HE11 (8 Mbps – 1200 Mbps) 2.4G: HE0-HE11 (8Mbps – 574 Mbps) 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio@ 6GHz 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio@ 5GHz 2x2:2 Stream Multiple-In, Multiple-Out (MIMO) Radio @2.4GHz HE20/HE40/HE80/HE160 support for 6 GHz HE20/HE40/HE80 support for 5 GHz HE20/HE40 support for 2.4 GHz DL SU-MIMO and MU-MIMO TxBF (Transmit Beamforming)
IOT Radio	Thread, Zigbee®, Bluetooth® 5.2 Low Energy, IEEE 802.15.4
Interfaces	Eth0, Eth1: (2) Wired Ethernet ports (RJ-45) (1) 100/1000/2500Mbps auto-sensing link speed Ethernet port, POE 802.3at (1) 10/100/1000 Mbps auto-sensing link speed Ethernet port 802.3az Energy Efficient Ethernet(EEE) USB 2.0, Type A, 5V/500mA
Power Specifications	IEEE 802.3at PoE Power
Power Options	Power Draw: Typical: 12.3W; Max: 13.8W (w/o USB) Typical: 15W; Max: 16.6W (w USB) 802.3at Power over Ethernet (PoE) capable Gigabit Ethernet port (RJ-45 power input pins: Wires 4,5,7,8 or 1,2,3,6)
Physical	Dimensions: 8" x 8" x 1.5" (205mm x 205mm x 37mm) Weight: 1.88 pounds (.85 kg) Kensington lock slot Trusted Platform Module(TPM)
Internal Antennas	(2) Integrated single band, 5.925-7.125 GHz omnidirectional antennas (2) Integrated dual band, 2.4-2.5 GHz and 5.1-5.8 GHz omnidirectional (2) Integrated dual band, 2.4-2.5 GHz and 5.1-5.8 GHz omnidirectional for sensor (1) Integrated dual band, 2.4-2.5 GHz omnidirectional for IoT
Mounting	AP support 15/16 flush ceiling tile include in box Wall mount included in box or sold as an accessory Ceiling Tile Recessed 15/16 sold as accessory Beam sold as an accessory Junction Box sold as an accessory IL or 9/16 t-bar sold as an accessory SL (Silhouette) sold as an accessory Wing Main Plate adaptor sold as an accessory Built in slot for Kensington
Environmental	Operating: AP4000: 0 to 50°C Storage: -40 to 70°C Humidity: 0% to 95% (non-condensing)
Environmental Compliance	EU RoHS – 2011/65/EU EU WEEE – 2012/19/EU EU REACH - Regulation (EC) No 1907/2006 – Reporting EU SCIP – EU Waste Framework Directive China RoHS – SJ/T 11363-2006 Taiwan RoHS CNS 15663(2013.7)
Regulatory Compliance	USA Part 15C - 15.247 Part 15E - 15.407 Part 15B EMC class B RF exposure - KDB 447498D01V06 FCC Part1.1310 ANSI C63.4 test methods IEC 60601-1-2 EMC for medical devices Canada RSS 247 for 2.4G 802.11 IECS-003 class B RF exposure - RSS-102: Issue 5, 2015 CE 2014/53/EU Radio Equipment Directive EN 300 328, EN 301 893, EN 302 502, EN 300 440 EN301 489 1, EN 301 489 17, EN 62311, EN 62479, EN 50385
Regulatory and Safety	North American ITE UL 60950-1 2nd edition Listed Device (U.S.) CSA 22.2 No. 60950-1 2nd edition 2014(Canada) UL/CuL 62368-1 Listed UL 2043 Plenum Rated European ITE EN 62368-1 2014/35/EU Low Voltage Directive International ITE CB Report and Certificate per IEC 60950-1 + National Differences CB Report and certificate IEC 62368-1 AS/NZS 60950-1 (Australia /New Zealand)
EMI/EMC Standards	North American EMC Standards FCC CFR 47 part 15 Class A (USA) ICES-003 Class A (Canada) European EMC Standards EN 55032 Class A EN 55035 EN 55011 EN 61000-3-2: (Harmonics) EN 61000-3-3 (Flicker) EN 300 386 (EMC Telecommunications) 2014/30/EU EMC Directive International EMC Certifications CISPR 32 Class A (International Emissions) AS/NZS CISPR32 CISPR 24 Class A (International Immunity) IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 IEC/EN 61000-4-11
Warranty	The AP302W is covered under Extreme’s Universal LLW policy.
