AP650/650X :: WI-FI 6 Premium :: Wireless Access Points :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme AP650/650X Access Points competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Radio Specifications
Wireless Frequency Range	USA: 2.400 ~ 2.483 GHz, 5.15 ~ 5.35 GHz, 5.47 ~ 5.725 GHz, 5.725 ~ 5.85 GHz Europe: 2.400 ~ 2.483 GHz, 5.15 ~ 5.35 GHz, 5.47 ~ 5.725 GHz Japan: 2.400 ~ 2.497 GHz, 5.15 ~ 5.35 GHz, 5.47 ~ 5.725 GHz
Modes	IEEE802.11a 5 GHz OFDM IEEE802.11b 2.4 GHz DSSS/CCK IEEE802.11g 2.4 GHz OFDM IEEE802.11n 2.4 GHz/5 GHz OFDM IEEE802.11ac OFDM IEEE802.11ax OFDMA
Channel Support	802.11 b/g/n/ax US/Canada: 11 (1 ~ 11) Europe: 13 (1 ~ 13) Japan: 11b: 14 (1~13 or 14th), 11g: 13 (1 ~ 13) China: 13 (1 ~ 13) 802.11 a/n/ac/ax US/Canada: 24 non-overlapping channels Europe: 19 non-overlapping channels Japan: 19 non-overlapping channels China: 5 non-overlapping channels
Modulation Technology	802.11 Legacy a/b/g DSSS (DBPSK, DQPSK, CCK) OFDM (BPSK, QPSK, 16-QAM, 64-QAM) DSSS with DBPSK (1 Mbps), DQPSK (2 Mbps), and CCK (5.5 & 11 Mbps) OFDM with BPSK (6, 9 Mbps), QPSK (12, 18 Mbps), 16QAM (24, 36 Mbps), 64QAM (48, 54 Mbps) 802.11n OFDM (BPSK, QPSK, 16-QAM, 64-QAM) 802.11ac OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM) 802.11ax OFDMA (1024-QAM)
Interfaces	1x 10/100/1000 Gigabit Ethernet 1x 2.5 mGig RJ-45 Console Port USB Interface 802.3az supported Redundant PoE Capable
Radios	Dual Radio AP, 2.4 GHz/5GHz and 5GHz radios supporting dual band or dual 5GHz operation 2.4 GHz/5 GHz, 802.11b/g/n/ax, 4x4 5 GHz, 802.11 a/n/ac/ax, 4x4 160 MHz, 1024-QAM supported 1x Bluetooth/Zigbee radio
Power Consumption	DC Power: Typical 18.78 W; Max 20.65 W 802.3at PoE Power: Typical 15.72 W; Max 19.92 W
Environmental	Operating Temperature: 0 to 40 °C Storage Temperature: -40 to 70 °C Humidity: 10 to 95%
Physical	Dimensions: 225mm x 225mm x 37.5mm Weight: 2.6lb (1.18kg) Wall or ceiling mountable MTBF: 363,162 Hours @ 25 °C (estimate) RoHS: -2 Compliant TPM chip for added security
Antennas	4x integrated dual band 2.4-2.5 GHz/5.1-5.8 GHz omnidirectional antennas 4x integrated single band, 5.1-5.8 GHz omnidirectional antennas 1x internal Bluetooth/ZigBee antenna
Peak Antenna Gain	2.4 GHz omnidirectional, gain 5.0 dBi 5 GHz omnidirectional, gain 6.0 dBi Bluetooth/ZigBee omnidirectional, gain 4.2 dBi
Environmental Compliance	UL2043 - Plenum Rated
Regulatory Compliance	Product Safety IEC 60950-1, EN 60950-1, UL 60950-1, CSA 22.2 No.60950-1-03, AS/NZS 60950.1, RoHS Directive 2011/65/EU Radio Approvals FCC CFR 47 Part 15, Class B ICES-003, Class B FCC Subpart C 15.247 FCC Subpart E 15.407 RSS247 AS/NZS4268 + CISPR32 IEC/EN 60601-1-2 EN 50385 EN 301 489-1 EN 301 489-3 EN 301 489-17 EN 55032 (Class B) EN 55024 EN 300 328 EN 301 893 EN 300 440
