Extreme AP560h Access Points

General

Fully-Featured Enterprise Class AP

Number of Wi-Fi Radios

2

Internet of Things (IoT) Radio

Dual mode selectable (2.4 GHz with coexistence) Bluetooth Low Energy (BLE) 4.1- Single and Dual mode operation (Classic and Low Power Profiles 802.15.4 -2011)

MIMO Implementation for High-Performance 11ax, 11ac, and 11n

4x4

Number of Spatial Streams

4 per radio

Product Features

AP560h/AP560h

Number of Simultaneous Streams

5 GHz radio:

Four spatial stream Multi User (MU) MIMO for up to 4.8 Gbps wireless data rate to up to four 1 SS or two 2SS HE160 802.11ax DL-MU-MIMO capable client devices simultaneously (max)*

Four spatial stream Multi User (MU) MIMO for up to 2.4 Gbps wireless data rate to up to four 1 SS or two 2SS HE80 802.11ax DL-MU-MIMO capable client devices simultaneously (typical)*

2.4 GHz radio:

Four spatial stream Multi User (MU) MIMO for up to 1.148 Gbps wireless data rate to up to four 1 SS or two 2SS HE40 802.11ax DL-MU-MIMO capable client devices simultaneously (max)*

Four spatial stream Multi User (MU) MIMO for up to 572 Mbps wireless data rate to up to four 1 SS or two 2SS HE20 802.11ax DL-MU-MIMO capable client devices simultaneously (typical)*

Maximum 2.4 GHz Radio

1.148 Gbps (40 MHz)

Maximum 5 GHz Radio

4.8 Gbps (Full 5 GHz 160 MHz)

Number of SSIDs Supported Per Radio/Total

8/16

Simultaneous Users Per Radio/Total

256/512 Per AP

Mode of Operation

Semi-autonomous/Autonomous

Plug and Play Operation/Zero Touch Deployment

Yes

Security and Standards

WPA, WPA2 (AES), WPA3*, 802.11i, 802.1x, IPSec, IKEv2, PKCS #10, X509 DER/PKCS #12, SSL

Multiple Operating Modes

Centralized Data Paths Within Same SSID

Application Based Distributed and Centralized Data Paths Within Same User/Device Session

Simultaneous RF Monitoring and Client Services

BYOD/Device Fingerprinting Visibility
