Details:

Description

Radio Specifications
SSID per Radio/Total	8/16
Users per Radio/Total	512/1024
TPM (Trusted Platform Module)	Yes
802.11a
Operating Frequency	5.150–5.850 GHz
Modulation	Orthogonal Frequency Division Multiplexing (OFDM)
Rates (Mbps)	54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback
802.11b
Operating Frequency	2.4–2.5 GHz
Modulation	Direct-Sequence Spread-Spectrum (DSSS)
Rates (Mbps)	11, 5.5, 2, 1 w/ auto fallback
802.11g
Operating Frequency	2.4–2.5 GHz
Modulation	Orthogonal Frequency Division Multiplexing (OFDM)
Rates (Mbps)	54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback
802.11n
Operating Frequency	2.4–2.5 GHz & 5.150–5.850 GHz
Modulation	802.11n Modulation
Features	HT20 High-Throughput (HT) Support (for both 2.4 GHz and 5 GHz) HT40 High-Throughput (HT) Support for 5 GHz A-MPDU and A-MSDU Frame Aggregation CSD and CDD
802.11ac
Operating Frequency	5.150–5.850 GHz
Modulation	802.11ac Modulation (256-QAM)
Rates (Mbps)	MCS0 – MCS9 (6.5MBps - 800Mbps)
Features	5G: 4x4 Multiple-In, Multiple-Out (MIMO) Radio (MRC) Rates (Mbps): MCS0–MCS9 (6.5Mbps – 3467Mbps), NSS = 1-4. 4x4:4 Stream Multiple-In, Multiple-Out (MIMO) Radio VHT20/VHT40/VHT80/VHT160 support TxBF (Transmit Beamforming)
802.11ax
Operating Frequency	2.4–2.5 GHz & 5.150–5.850 GHz
Modulation	802.11ax Modulation (1024-QAM)
Features	Dual-band OFDMA Rates (Mbps): 5G: HE0-HE11 (8 Mbps – 4800 Mbps) 2.4G: HE0-HE11 (8Mbps – 1148 Mbps) HE20/HE40/HE80/HE160 support for 5 GHz HE20/HE40 support for 2.4 GHz DL SU-MIMO and MU-MIMO (MRC) TxBF (Transmit Beamforming)
Interfaces
Ethernet Port 1	(1) 100/1000/2500/5000 Mbps auto-negotiation Ethernet port, RJ45 PoE (802.3at), (802.3bz supported)
Ethernet Port 2	(1) 10/100/1000 Mbps auto-negotiation Ethernet port, RJ45
USB Port	USB3.0, Type A, 0.5A
Power Options
Power Draw	Typical: 18 W; Max: 22 W
Power over Ethernet (PoE)	802.3at PoE capable (Full Functionality)
PoE Injector	802.3af PoE injector (Reduced Functionality)
Physical
Dimensions	9" x 9" x 1.89" (229mm x 229mm x 48.15mm)
Weight	AP510i: 3.4 lbs (1.45 kg), AP510e: 3.45 lbs (1.56 kg)
Antennas
AP510i - Internal Antennas	(4) Integrated dual band, 2.4-2.5 GHz and 5.1-5.8 GHz omnidirectional antennas (4) Integrated single band, 5.1-5.8 GHz omnidirectional antennas (1) Integrated single band, 2.4-2.5 GHz omnidirectional antennas for BLE
AP510e - External Antennas	8 RP SMAs connectors 1 RP SMAs connector for BLE
Mounting
Mounting Options	Wing Bracket Compatible, Extreme Multi-Tbar, Kensington Lock
Security
Security Features	WPA, WPA2(AES), WPA3, 802.11i, 802.11x, IPSec, IKEv2, PKCS#10, x509 DER / PKCS #12 SSL
Environmental
Operating Temperature	AP510i: 0 to 40°C, AP510e: -20 to 55°C
Storage Temperature	-40 to 70°C
Humidity	0% to 95% (non-condensing)
Electrostatic Discharge	15kV air, 8kV contact
Environmental Compliance	UL2043 - Plenum Rated
IOT Radio
BLE Radio	Bluetooth® Low Energy (BLE) and IEEE® 802.15.4 compliant
Regulatory Compliance
Product Safety Certifications	IEC 60950-1, EN 60950-1, UL 60950-1, CSA 22.2 No.60950-1-03 AS/NZS 60950.1
RoHS Directive	2011/65/EU
Radio Approvals	FCC CFR 47 Part 15, Class B ICES-003, Class B FCC Subpart C 15.247 FCC Subpart E 15.407 RSS247 AS/NZS4268 + CISPR32 IEC/EN 60601-1-2 EN 62479 EN 62311 EN 50385 EN 301 489-1
Support
Warranty	Limited Lifetime Warranty WiNG
