AP250 :: WI-FI 5 :: Wireless Access Points :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme AP250 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Radio Specifications
802.11a	150–5.850 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM) Modulation Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback
802.11b	4–2.5 GHz Operating Frequency Direct-Sequence Spread-Spectrum (DSSS) Modulation Rates (Mbps): 11, 5.5, 2, 1 w/auto fallback
802.11g	4–2.5 GHz Operating Frequency Orthogonal Frequency Division Multiplexing (OFDM) Modulation 20 dBm (100 mW) Transmit Power Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback
802.11n	4–2.5 GHz & 5.150–5.850 GHz Operating Frequency 11n Modulation Rates (Mbps): MCS0–MCS23 (6.5Mbps - 450Mbps) 3x3:3 Stream Multiple-In, Multiple-Out (MIMO) Radio HT20 High-Throughput (HT) Support for both 4 GHz and 5 GHz A-MPDU and A-MSDU Frame Aggregation
802.11ac	150–5.850 GHz Operating Frequency 11ac Modulation (256-QAM) Rates (Mbps): MCS0–MCS9 (6.5Mbps - 1300Mbps), NSS = 1-3 3x3:3 Stream Multiple-In, Multiple-Out (MIMO) Radio VHT20/VHT40/VHT80 support
Interfaces	Two Autosensing 10/100/1000 BASE-T Ethernet ports. PoE/PoE+ capability on one of the ports RJ-45 console port Standard USB port IEEE 802.3af PoE Power: Full 3x3:3 802.11ac MU-MIMO performance, BLE, and Dual 5 GHz. No USB port, no 2nd Ethernet IEEE 802.3at PoE Power: full set of features (all of the above plus USB port and 2nd Ethernet port) 4 GHz typical power draw: 17 dBm, max 20 dBm 5 GHz typical power draw: 18 dBm, max 19 dBm
Physical	WxDxH: 25” x 7.25” x 1.87” (18.4 cm x 18.4 cm x 1.87 cm) [plus .25”, mounting hardware – 2.12” (5.4 cm) H total] Weight: 1.8 lb (0.81 kg)
Antennas	6 + 2 internal Wi-Fi antennas for spatial and polarization diversity 1x BLE internal antenna
Mounting	Desktop Ceiling Tile Recessed 15/16”, 3/8”, 9/16” (sold as an accessory) Ceiling Tile flush 3/8”, 9/16” (sold as an accessory) Suspend Mount (sold as an accessory) Plenum Mount (sold as an accessory) Silhouette and Interlude (sold as an accessory) TPM chip for added security
Environmental	Operating: 0 to +40°C Storage: -40 to +70°C Humidity: 95%
Environmental Compliance	UL2043
