Details:

Description

Product Fatures	AP 7612
802.11ac Capabilities
802.11n	3x3 MIMO with 3 spatial streams 20 and 40 MHz channels 450 Mbps data rates per radio Packet aggregation (AMSDU, AMPDU) Reduced Interface Spacing 802.11 DFS MIMO Power Save (Static and Dynamic) Advanced forward error correction coding: STBC, LDPC Additional radio can support either 24x7 WIPS sensing and spectrum analysis or Dynamic Frequency Selection (DFS) Scan Ahead
Physical Characteristics
Dimensions	9.0 in. L x 10.0 in. W x 2.6 in. H, 22.8 cm L x 25.4 cm W x 6.6 cm H
Weight	5.6 lbs/2.54 kg
Housing	Outdoor IP67 rated, diecast aluminum, corrosion-resistant enclosure, salt, fog, rust ASTM B117
LEDs Activity Indication	2 top-mounted LEDs
Uplink	2 ports (GE1, GE2) auto-sensing 10/100/1000Base-T Ethernet; 802.3at on GE1 LAN port
Antenna Connectors	8 N-type ports
Console Port	Outdoor-rated RJ45 console port
Multi-Band Security Sensor	Outdoor 24x7 integrated Wireless Intrusion Prevention System (WIPS)
User Environment
Operating Temperature	-22° F to 140° F/-30° C to 60° C
Storage Temperature	-40° F to 185° F/-40° C to 85° C
Operating Humidity	5 to 95% RH non-condensing
IP Sealing	IP67
Operating Altitude	8,000 ft. at 54° F/12° C
Storage Altitude	30,000 ft. at 82° F/28° C
Wind Rating	150 mph
Electrostatic Discharge	15kV air, 8kV contact
Operation Shock	IEC60721-3-4, Class 4M3, MIL STD 810F
Vibration	IEC60721-3-4, Class 4M3
Power Specifications
Operating Voltage	36-57VDC
Operating Current	625mA at 48V in 802.3at mode
Networking Specification
Layer 2 and Layer 3	Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE, and LLDP
Security	Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WPA TripleMethodology Rogue Detection: 24x7 dual-band WIPS sensing, MU-assisted, on-board IDS, and secure guest access ( hotspot)
Quality of Service (QoS)	WMM, WMM-UAPSD, 802.1p, Diffserv, and TOS
Radio Specifications
Wireless Medium	Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO)
Network Standards	IEEE 802.11a/b/g/n, 802.11d and 802.11i WPA2, WMM, and WMM-UAPSD
Data Rates Supported	802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48; 54 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48; 54 Mbps 802.11n: MCS 0-23 up to 450 Mbps
Operating Channels	2.4 GHz Band: Channel 1 through Channel 13 5 GHz Band: Channel 36 through Channel 165 * Channel availability depends on local regulatory restrictions
Maximum Available Transmit Power per Chain (conducted)	2.4GHz: 23dBm, 5.2GHz: 20dBm
Maximum Available Transmit Power per AP (composite, 0dBi antenna)	2.4 GHz: 27.7dBm, 5.2 GHz: 24.7dBm
Antenna Configuration	3x3 MIMO (transmit/receive on all three antennas) and green mode (dynamical antenna selection)
Transmit Power Adjustment	1dB increment from 0dBm to max
Operating Frequencies	2412 to 2472 MHz, 5180 to 5825 MHz
Accessories
Mounting	Stainless Steel Mounting Bracket (KT-147407-02) Extension Mounting Kit (KT-150173-01)
Outdoor 802.3AT POE	AP-PSBIAS-7161-US
Single Port Midspan	PD-9001GO-ENT (International) PD-MBKOUT Mounting Bracket for Outdoor Midspans
External antenna options (see WLAN Antenna Guide for external antenna options)
Regulatory
Safety Certifications	UL / cUL 60950-1, IEC / EN60950-1, RoHS
Radio Approvals	FCC (USA), Industry Canada, CE ( Europe), Australia
Warranty
Warranty	One (1) year on AP 8163; 30 days on accessories; 90 days on software
