WiNG AP 7602 Wall Plate

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme WiNG WiNG AP 7602 Wall Plate competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

802.11ac Capabilities
Multi-operational modes	Real-time dual-band, dual-concurrent 2.4GHz + 5GHz concurrent single stream (1x1:2.4G + 1x1:5G) 2.4GHz or 5GHz dual stream (2x2:2.4G or 2x2:5G)
Channel Support	20, 40, 80 MHz Channels
Advanced Features	AMSDU, AMPDU, RFIS, STBC (when running 2x2 single band), LDPC
MIMO Power Save	Static and dynamic
Maximal Ratio Combining (MRC)	When running single-band mode
Standard	802.11ac
Networking
Layer 2 and Layer 3	Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE, and LLDP
Security	Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WIDs/WIPs, IPSec, RADIUS server
QoS	WMM, WMM-UAPSD, 802.1p, COS, Diffserv. Role-based QoS and packet marking
Radio Specifications
Mode: 2.4GHz Maximum conducted Tx power	19dBm
Mode: 5GHz Maximum conducted Tx power	17dBm
Transmit Power Increments	1dBm
Operating Channels and Frequencies	2.4 GHz Band: Channel 1-13; 2412 to 2472 MHz 5.2 GHz Band: Channel 36-165; 5180 to 5850 MHz 2.4 GHz Bluetooth: Channel 0-78 Channel availability depends on local regulatory restrictions
Wireless Medium	DSSS, OFDM, MIMO
Network Standards
Standards	WPA2, WMM, WMM-UAPSD, L2TPv3, Client VPN, MESH, Captive Portal server, BT 2.0, BLE 4.0
Supported Data Rates	802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, and 54 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps 802.11n: MCS HT 0-15 up to 300 Mbps 802.11ac: MCS VHT 0-9 up to 867 Mbps
