WiNG AP 7562 :: Controllers :: Wireless Access Points :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme WiNG AP 7562 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Product Fatures	AP 7562
802.11ac Capabilities
Dual radios; supports 256-QAM 3X3 MIMO with 3 Spatial Streams 20, 40, and 80 MHz Channels 1.9 Gbps data rates on dual concurrent radio operations Packet Aggregation (AMSDU, AMPDU) Reduced Interface Spacing	802.11 DFS MIMO Power Save (Static and Dynamic) Advanced forward error correction coding: STBC, LDPC 802.11ac transmit beamforming Maximal Ratio Combining (MRC)
Physical Characteristics
Dimensions	9.0 in. L x 10.0 in. W x 2.6 in. H 22.8 cm L x 25.4 cm W x 6.6 cm H
Weight	5.6 lbs./2.54 kg
Housing	Outdoor IP67-rated, die-cast aluminum, corrosion resistant enclosure, salt, fog, rust ASTM B117
Available Mounting	KT-147407-01 Outdoor Mounting KT-147407-02 Outdoor Stainless Steel Mounting
LEDs Activity Indication	2 top-mounted LEDs; activity indication
LAN Ethernet	2x IEEE 802.3 Gigabit Ethernet auto-sensing
Antenna	See Antenna Guide for antennas
Antenna Connectors	6-N-Type Connectors
Console Port	Outdoor rated RJ45 console port
User Environment
Operating Temperature	-40° F to 140° F/-40° C to 60° C
Storage Temperature	-40° F to 185° F/-40° C to 80° C
Operating Humidity	95% RH non-condensing
Electrostatic Discharge	Condensing Electrostatic Discharge
Operating Altitude	8,000 ft. at 54 °F/12 °C
Storage Altitude	30,000 ft. at 82 °F/28 °C
Wind Rating	150 mph
Operational Shock	IEC60721-3-4, Class 4M3, MIL STD 810F
Operational Vibration	IEC60721-3-4, Class 4M3
Shock and Vibration	ETSI 300-19-2-4 spec T41.E 4M3
Power Specifications
Operating Voltage	36-57 VDC
Operating Current	354mA at 48V in 802.3at
Power in (PoE)	802.3at, 802.3af
Certifications
Wi-Fi Alliance (WFA) certified 802.11 a/b/g/n/ac
Networking Specifications
Layer 2 and Layer 3	Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE, and LLDP
Security	Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WPA TripleMethodology Rogue Detection: 24x7 dual-band WIPS sensing, on-board IDS and secure guest access (hotspot) with captive portal, IPSec, and RADIUS Server
Quality of Service (QoS)	WMM, WMM-UAPSD, 802.1p, Diffserv and TOS
Radio Specifications
Wireless Medium	Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO)
Network Standards	IEEE 802.11a/b/g/n/ac, 802.11d and 802.11i WPA2, WMM, WMM-UAPSD, L2TPv3, Client VPN, MESH, Captive Portal server
Data Rates Supported	802.11b/g: 1,2,5.5,11,6,9,12,18,24,36,48, and 54 Mbps 802.11a: 6,9,12,18,24,36,48, and 54 Mbps 802.11n: MCS 0-23 up to 450 Mbps; Turbo mode (256 QAM) on 2.4 GHz band up to 600 Mbps 802.11ac: MCS 0-9 up to 1.3 Gbps
Operating Channels	2.4 GHz Band: Channel 1 through Channel 13 5.2 GHz Band: Channel 36 through Channel 165 * Channel availability depends on local regulatory restrictions
Antenna Configuration	3x3 MIMO (transmit/receive on all three antennas)
Transmit Power Adjustment	1 dB increment
Operating Frequencies	2412 to 2472 MHz, 5180 to 5850 MHz
Regulatory
Product Safety Certifications	UL / cUL 60950-1, IEC / EN60950-1, RoHS
Radio Approvals	FCC (USA), Industry Canada, CE (Europe), and TELEC (Japan)
