WiNG AP 7522 :: Controllers :: Wireless Access Points :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme WiNG AP 7522 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Product Fatures	AP 7522
802.11ac Capabilities
Capabilities	Dual-band radios; supports 256-QAM 2X2 MIMO with 2 Spatial Streams 20, 40, and 80 MHz Channels 1.267 Gbps data rates on dual concurrent radio operations Packet Aggregation (AMSDU, AMPDU) Reduced Interface Spacing 802.11 DFS MIMO Power Save (Static and Dynamic) Advanced forward error correction coding: STBC, LDPC 802.11ac transmit beamforming Maximal Ratio Combining (MRC)
Physical Characteristics
Dimensions	7.1 in. L x 6.5 in. W x 1.6 in. H, 180 mm L x 165 mm W x 41 mm H
Weight	1.8 lbs/0.82 kg
Housing	Plenum-rated housing (UL2043)
Mounting	No additional hardware required to mount
Configurations	Above drop ceiling, under ceiling or on wall
LEDs Activity Indication	2 top-mounted LEDs; activity indication
LAN Ethernet	1x IEEE 802.3 Gigabit Ethernet auto-sensing
Antenna	4dBi - 2.4 GHz band; 6 dBi - 5GHz band
Antenna Connectors	Two RP SMAs (External only — AP-7522-67040-xx)
Console Port	RJ45
Power Specifications
Operating Voltage	48V
Operating Current	280mA at 48V
Integrated PoE Support	802.3af
Networking Specification
Layer 2 and Layer 3	Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE and LLDP
Security	Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WPA TripleMethodology Rogue Detection: 24x7 dual-band WIPS sensing, on-board IDS, and secure guest access (hotspot)
Quality of Service (QoS)	WMM, WMM-UAPSD, 802.1p, Diffserv, and TOS
Radio Specifications
Wireless Medium	Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO)
Network Standards	IEEE 802.11a/b/g/n/ac, 802.11d and 802.11i WPA2, WMM, and WMM-UAPSD
Data Rates Supported	802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, and 54Mbps, 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54Mbps, 802.11n: MCS 0-23 up to 300Mbps; Turbo mode (256QAM) on 2.4G band: up to 400Mbps, 802.11ac: MCS 0-9 up to 866.7Mbps
Operating Channels	2.4 GHz band: channel 1 through channel 13 5.2 GHz band: channel 36 through channel 165 Channel availability depends on local regulatory restrictions
Antenna Configuration	2x2 MIMO (transmit/receive on both antennas)
Transmit Power Adjustment	1dB increment
Operating Frequencies	2412 to 2472 MHz, 5180 to 5825 MHz
Environmental
Operating Temperature	Internal antennas: 32° F to 104° F/ 0° C to 40° C External antennas: -4° F to 104° F/ -20° C to 40° C
Storage Temperature	-40°F to 158°F/-40°C to 70°C
Operating Humidity	85% RH non-condensing
Electrostatic Discharge	Internal AP-7522-67030-xx: 15kV air, 8kV contact External AP-7522-67040-xx: 12kV air, 6kV contact
Certifications
	Wi-Fi Alliance (WFA) certified 802.11a/b/g/n/ac
Regulatory
Safety Certifications	UL / cUL 60950-1, IEC / EN60950-1, UL2043, RoHS
Radio Approvals	FCC (USA), EU, TELEC
Accessories
Power Supply	(37215) PWR 12VDC, 2A, 2.5mm x 5.5mm connector
PoE	(PD-3501G-ENT) Single Port 802.3AF Midspan Device
Mounting	Mounting Plate for Indoor APs (37201) Include in box Universal Mounting Kit For Ewlan APS (KT-135628-01) BEAM CLIP for Mounting Plate (BRKT-000147A-01)
Maximum Conducted Transmit Power – One Antenna TX Power*
Internal Antennas (AP-7522-67030-xx)	2.4 GHz Band : 20 dBm 5 GHz Band : 20 dBm
External Antennas (AP-7522-67040-xx)	2.4 GHz Band : 19 dBm 5 GHz Band : 18 dBm
Maximum Conducted Transmit Power – Two Antennas TX Power*
Internal Antennas (AP-7522-67030-xx)	2.4 GHz Band : 23 dBm 5 GHz Band : 23 dBm
External Antennas (AP-7522-67040-xx)	2.4 GHz Band : 22 dBm 5 GHz Band : 21 dBm
