Details:

Description

General	Fully-Featured Enterprise Class AP 2 Wi-Fi Radios 2x2 MIMO Implementation for High-Performance 11ac & 11n Throughputs 2 Spatial Streams 2 Simultaneous Users (MU-MIMO) 300 Mbps Maximum Throughput 2.4GHz Radio 867 Mbps Maximum Throughput 5GHz Radio 1.167 Gbps Maximum Throughput Per AP 50,000 pps RFC2285 Wire/Wireless Forwarding Rate 8/16 SSIDs Supported Per Radio/Total 240/480 Per AP Simultaneous Users Per Radio/Total 30 or less Simultaneous Voice calls (802.11b, G711, R>80) Semi-autonomous Mode of Operation Plug and Play Operation/Zero Touch Deployment Security and Standards: WPA, WPA2 (AES), 802.11i, 802.1x, IPSec, IKEv2, PKCS #10, X509 DER / PKCS #12, SSL
Internet of Things (IoT) Radio	Dual mode selectable (2.4 GHz with Co-Existence): Bluetooth Low Energy (BLE) 4.1 Single and Dual mode operation (Classic and Low Power Profiles 802.15.4 -2011)
Multiple Operating Modes	Intelligent Thin AP: Encryption, Security, QoS and RF Management Services done at AP Distributed and Centralized Data Paths Within Same SSID Application Based Distributed and Centralized Data Paths Within Same User / Device Session Simultaneous RF Monitoring and Client Services BYOD / Device Fingerprinting Visibility Application / Layer 7 Visibility and Control In-Channel WIDS In-Channel WIPS Dedicated Multi-Channel WIDS (Guardian Mode) Dedicated Multi-Channel WIPS (Guardian mode) Dedicated Multi-Channel RF Spectrum Analysis and Fingerprinting Locates Devices and Threats via RF Triangulation Self-Forming and Self-Healing Meshing Remote Access Point Hardware-Based, End-to-End Data and Control Plane Encryption Private and Public Cloud Deployments SSL
Hybrid Operation	Security Scanning and Serve Clients On Same Radio Security Scanning and Spectrum Analysis On Same Radio Spectrum Analysis and Serve Clients On Same Radio Multi-Channel Dedicated Security Scanning and Spectrum Analysis
Radio Characteristics	Cellular coexistence Max Total Conducted Power (does not include antenna gain)* Radio 1 (5GHz): 26 dBm (AP3915i), 23 dBm (AP3915e) Radio 2 (2.4GHz): 26 dBm (AP3915i), 23 dBm (AP3915e) IoT Radio: 3 dBm Max Antenna Gain (Integrated Antenna) Radio 1 (5GHz): 5.3 dBi Radio 2 (2.4GHz): 4.3 dBi IoT: 4.1 dBi Adaptive Radio Management Dynamic Channel Control: 802.11h: DFS and TPC support (ETSI) Efficient Use of the Spectrum with A Multi-Channel Architecture Automatic Transmit Power and Channel Control Self-Healing with Coverage Gap Detection Band Steering with Multiple Steering Modes Spectrum Load Balancing of Clients Airtime Fairness Performance Protection In Congested RF Environments Fast Transition Roaming (802.11k) Mitigates Co-Channel Interference with Coordinated Access Mitigates Adjacent Channel Interference with Optimized Receive Sensitivity Efficient Reuse of Channels At Shorter Intervals Mitigates Non 802.11 Interference Without Dedicated Radios Probe Suppression and Client Link Monitoring Management Frame Protection (802.11w)
Quality of Service	Quality of Service (WMM, 802.11e) Power Save (U-APSD) Fast Secure Roaming and Handover Between APs (802.11r) Pre-Authentication (Pre-Auth) Opportunistic Key Caching (OKC) Bonjour/LLMNR/UPNP Identification, Containment and Control Supports Voice, Video, and Data Using the Same SSID Prioritizes Voice Over Data for Both Tagged and Untagged Traffic Rate Limiting (Rule and User-Based) Rule and Role Based QoS Processing Multicast Rate Control Multicast to Unicast Conversion Adaptable Rate Multicast Power Save Mode Optimization for Multicast
Wireless Services	Media Access Protocol: CSMA/CA with ACK Data Rates: 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps 802.11n: Performance Table, check on datasheet 802.11ac: Performance Table, check on datasheet Receiver Sensitivity: 802.11a: -94dBm @ 6Mbps, -79dBm @ 54Mbps 802.11g: -95dBm @ 6Mbps, -79dBm @ 54Mbps 802.11n: See 802.11n Receiver Sensitivity Table, check on datasheet 802.11ac: See 802.11ac Receiver Sensitivity Table, check on datasheet Frequency Bands: 802.11 ac/a/n: 5.15 to 5.25 GHz (FCC/IC/ETSI) 5.25 to 5.35 GHz (FCC/IC/ETSI)* 5.47 to 5.725 GHz (FCC/IC/ETSI)* 5.725 to 5.850 GHz (FCC/IC) 802.11b/g/n: 2.400 to 2.4720 GHz (FCC/IC) 2.400 to 2.4835 GHz (ETSI) Wireless Modulation: 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM with OFDM 802.11ac Packet Aggregation: A-MPDU, A-MSDU 802.11ac Very High Throughput (VHT): VHT20/40/80 802.11ac Advanced Features: LDPC, STBC, Maximum Likelihood (ML) Detection 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM 802.11n High-throughput (HT) support: HT 20/40 802.11n Packet aggregation: A-MPDU, A-MSDU 802.11n Advanced Features: LDPC, STBC and TxBF 802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM 802.11g: DSSS and OFDM 802.11b: DSSS
Interfaces	Uplink: 1x 10/100/1000 Mbps auto-sensing Ethernet port Console Port: RJ45 USB Port: USB 2.0 (AP3915e) Ext. 12VDC
Mounting	Integrated Wall Mounting Single/Dual Gang (Junction) Box Installation Drop-ceiling mounting bracket (p/n: 37201 included)
Environmental	Plenum rated (UL 2043) (AP3915i) Operating Temperature: AP3915i 32° F to 104° F/ 0° C to +40° C Humidity: 0%-95% (noncondensing) Operating Temperature: AP3915e -4° F to 131° F/ -20° C to +55° C ambient temperature anywhere -4° F to 140° F/ -20° C to +60° C ambient temperature near sea level Storage Temperature -40° C to +70° C (-58° F to +158° F) Transportation Temperature -40° C to +70° C (-58° F to +158° F)
Wireless and EMC Compliance	FCC CFR 47 Part 15, Class B ICES-003 Class B FCC Subpart C 15.247 FCC Subpart E 15.407 RSS-247 EN 301 893 EN 300 328 EN 301 489 1 & 17 EN 50385 EN 55032 (CISPR 32) EN 60601-1-2 AS/NZS4268 + CISPR32
Safety	IEC 60950-1 EN 60950-1 UL 60950-1 CSA 22.2 No.60950-1-03 AS/NZS 60950.1
Mechanical	Dimensions 6.34 in. diameter x 1.74 in. height / 161 mm. x 48.5mm (AP3915i) 6.89 in. length x 5.04 in. width x 1.06 in. height / 200 mm. x 41 mm (AP3915e) Weight 0.72 lbs/0.33 kg (AP3915i) 1.37 lbs/0.62 kg (AP3915e) Power Consumption (RMS — Excludes PSE Load) AP3915i: Typical: 11 W, Idle (radios ON): 4.8 W AP3915e: Typical: 10 W, Idle (radios ON): 4.8 W
Warranty	Limited Lifetime Hardware Warranty
