X620 Series :: Other Switches :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme X620 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	XX620-8t-2x	X620-10x	X620–16x	X620–16t	X620-16p
Ports	8 x 100Mb/1Gb/10GBASE-T with EEE (RJ45) 2 x 100Mb/1Gb/10GBASE-X SFP+ ports 1 x Serial console port RJ-45 1 x 10/100/1000BASE-T out-of-band management port USB 2.0 port	10 x 100Mb/1Gb / 10GBASE-X SFP+ ports 1 x Serial console port RJ-45 1 x 10/100/1000BASE-T out-of-band management port USB 2.0 port	16 x 100Mb / 1Gb / 10GBASE-X SFP+ ports 1 x Serial console port RJ-45 1 x 10/100/1000BASE-T out-ofband management port USB 2.0 port	12 x 100Mb / 1Gb / 10GBASE-T ports with EEE (RJ45) 4 x 100Mb/1Gb/10GBASE-T with EEE (RJ45) shared with 4 x 1Gb/10GBASE-X SFP+ (with 10GBASE-LRM support) 1 x Serial console port RJ-45 1 x 10/100/1000BASE-T out-ofband management port USB 2.0 port	12 x 100Mb / 1Gb / 2.5Gb / 5Gb / 10GBASE-T ports with EEE (RJ45) 4 100Mb/1Gb/10GBASE-T PoE+ and EEE (RJ45) shared with 4 1Gb/10GBASE-X SFP+ ports with 10GBASE-LRM support 16 Ports Power over Ethernet 8 ports 802.3bt Type 3 PSE 60W PoE++ (ports 5-12) 8 ports 802.3at PoE+ Type 2 PSE 30W (ports 1-4, 13-16) 1 x Serial console port RJ-45 1 x 10/100/1000BASE-T out-of-band management port USB 2.0 port
Power Supplies	Integrated 100W AC PSU RPS connector for external redundant PSU Side to side airflow	Integrated 100W AC PSU RPS connector for external redundant PSU Side to side airflow	Modular 300W power supply (up to two PSUs) AC and DC power options Mixed AC and DC configuration Front-Back or Back-Front airflow options	Modular 300W power supply (up to two PSUs) AC and DC power options Mixed AC and DC configuration Front-Back or Back-Front airflow options	Modular 750W AC power supply (up to two PSUs) 380W PoE power per PSU (720W total PoE power per system) Front-Back airflow
Dimensions	12in W / 10.3in D / 1.7in H (30.48cm / 26.2cm / 4.3cm)	12in W / 10.3in D / 1.7in H (30.48cm / 26.2cm / 4.3cm)	17in W / 17.4in D / 1.7in H (43.1cm / 44.1cm / 4.4cm)	17in W / 17.4in D / 1.7in H (43.1cm / 44.1cm / 4.4cm)	17in W / 17.4in D / 1.7in H (43.1cm / 44.1cm / 4.4cm)
Weight	6.37 lbs / 2.89 Kg	6.04 lbs / 2.74 Kg	11.1 lbs / 5.0 Kg (base system)	12.0 lbs / 5.5 Kg (base system)	12.0 lbs / 5.5 Kg (base system)
Performance	Line Rate 200Gbps / 148.8Mpps Switching Capacity	Line rate 200Gbps / 148.8Mpps Switching Capacity	Line rate 320Gbps / 238Mpps Switching Capacity	Line Rate 320Gbps / 238Mpps Switching Capacity	Line rate 320Gbps / 238Mpps Switching Capacity
CPU Memory	1GHz CPU 1GB DDR3 ECC memory 4GB eMMC Flash memory	1GHz CPU 1GB DDR3 ECC memory 4GB eMMC Flash memory	1GHz CPU 1GB DDR3 ECC memory 4GB eMMC Flash memory	1GHz CPU 1GB DDR3 ECC memory 4GB eMMC Flash memory	1GHz CPU 1GB DDR3 ECC memory 4GB eMMC Flash memory
Packet Buffers	2MB	2MB	2MB	2MB	2MB
Operating Conditions	0 º - 50ºC operation 10 % to 95% relative humidity, non-condensing 0 - 3000 meters altitude Shock (half sine): 98 m/ s2 (3 G), 11ms, 6 shocks Random vibration: 3 to 500Hz at 1.5 G rms
Power and Heat Dissipation
Minimum Heat Dissipation (BTU/hr) (Idle, no ports linked)	74 BTU/hr	60 BTU/hr	AC: 111 BTU/hr DC: 80 BTU/hr	AC: 175 BTU/hr DC: 148 BTU/hr	No PoE: 208 BTU/hr 720W PoE: 501 BTU/hr
Minimum Power Consumption (Watts) (Idle, no ports linked)	22 W	18 W	AC: 33 W DC: 23 W	AC: 51 W DC: 43 W	No PoE: 61 W 720W PoE: 867 W
Dissipation (BTU/hr) (fans high all ports)	177 BTU/hr	123 BTU/hr	AC: 214 BTU/hr DC: 180 BTU/hr	AC: 347 BTU/hr DC: 326 BTU/hr	No PoE: 328 BTU/hr 720W PoE: 684 BTU/hr
Maximum Power Consumption (Watts) (fans high all ports 100% traffic)	52 W	36 W	AC: 63 W DC: 53 W	AC: 102 W DC: 96 W	No PoE: 114 W 720W PoE: 920 W
Acoustic Specifications
Bystander Sound Pressure (Front-Back Airflow)	-	-	47.0 dB(A) up to 40ºC 65.7 dB(A) @ 50ºC (max)	47.2 dB(A) up to 35ºC 65.6 dB(A) @ 50ºC (max)	No PoE: 47.3 dB(A) up to 35ºC 65.6 dB(A) @ 50ºC (max) PoE: 50.5 dB(A) up to 35ºC (50% PoE power) 67.1 dB(A) @ 50ºC (100% PoE power)
Bystander Sound Pressure (Back-Front Airflow)	-	-	46.9 dB(A) up to 40ºC 64.8 dB(A) @ 50ºC (max)	46.9 dB(A) up to 30ºC 65.2 dB(A) @ 50ºC (max)	-
Bystander Sound Pressure (Side-Side Airflow)	35.6 dB(A) up to 25ºC 38.8 dB(A) up to 30ºC 65.4 dB(A) @ 50ºC (max)	28.2 dB(A) up to 35ºC 66.3 dB(A) @ 50ºC (max)	-	-	-
Declared Sound Power (Front-Back Airflow)	-	-	6.1 bels up to 40°C 8.0 bels @ 50°C (max)	6.2 bels up to 35°C 8.0 bels @ 50°C (max)	No PoE: 6.2 bels up to 35ºC 8.0 bels @ 50 ºC (max) PoE: 6.5 bels up to 35ºC (50% PoE power) 8.2 bels @ 50 ºC (100% PoE power)
Declared Sound Power (Back-Front Airflow)	-	-	6.1 bels up to 40°C 8.0 bels @ 50°C (max)	6.2 bels up to 30°C 8.1 bels @ 50°C (max)	-
Declared Sound Power (Side-Side Airflow)	4.8 bels up to 25ºC 5.2 bels up to 30ºC 7.9 bels @ 50ºC (max)	3.8 bels up to 35ºC 7.9 bels @ 50ºC (max)	-	-	-
