As a trusted Extreme, ServerMonkey offers the Extreme VDX 6740 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	VDX 6940-36Q	VDX 6940-144S
Form factor	1U	1U
Switching bandwidth (data rate, full duplex)	2.88 Tbps	2.88 Tbps
Switch performance	2.16 Bpps	2.16 Bpps
Port-to-port latency	800 ns	800 ns
Dimensions	Width: 44 cm (17.32 in.) Height: 4.4 cm (1.73 in.) Depth: 43.8 cm (17.22 in.)	Width: 44 cm (17.32 in.) Height: 8.7 cm (3.41 in.) Depth: 48.5 cm (19.1 in.)
Weight	8.9 kg (19.6 lb) without media; 10.1 kg (22.3 lb) with media	15.46 kg (34.1 lb) empty; 17.32 kg (38.2 lb) with media
10 GbE SFP+ ports	144 10 GbE ports using breakout cables	96 fixed 10 GbE ports and additional 48 10 GbE ports with breakout cables
1 GbE SFP	0	96
1/10 GBASE-T	0	0
40 GbE QSFP+	36	12
100 GbE QSFP28	0	4
40 GbE Ports on Demand (PoD)	24, 36	6, 12
10 GbE Ports on Demand (PoD)	N/A	64, 80, 96
Power supplies	Two internal, redundant, field-replaceable, loadsharing AC/DC power supplies	Two internal, redundant, field-replaceable, loadsharing AC/DC power supplies
Cooling fans	5 field-replaceable fans (FRUs); each fan FRU has 2 fans	4 field-replaceable fans (FRUs); each fan FRU has 1 fan
Airflow	Rear-to-front or front-to-rear airflow	Rear-to-front or front-to-rear airflow
Scalability Information
Connector options	Out-of-band Ethernet management: RJ-45 (fixed) Console management: RJ45 to RS-232 (fixed) Firmware and diagnostic: USB	Out-of-band Ethernet management: RJ-45 (fixed) Console management: RJ45 to RS-232 (fixed) Firmware and diagnostic: USB
Maximum VLANs	4,096	4,096
Maximum MAC addresses	112,000 (L2 MACs); fabric-wide 256,000 (CML)	112,000 (L2 MACs); fabric-wide 256,000 (CML)
Maximum port profiles (AMPP)	512	512
Maximum members in a standard LAG	16	16
Maximum per-port priority pause level	8	8
Maximum switches that a vLAG can span	8	8
Maximum members in a vLAG	64	64
Maximum jumbo frame size	9,216 bytes	9,216 bytes
Queues per port	8	8
DCB Priority Flow Control (PFC) classes	8	8
Maximum ACLs	10,000	10,000
Maximum ARP entries	84,000	84,000
Maximum IPv4 unicast routes	12,000	12,000
Maximum IPv6 unicast routes	3,000	3,000
DCB Priority Flow Control (PFC) classes	8	8
HA/ISSU	ISSU fully supported	ISSU fully supported
Mechanical
Bystander Sound Pressure
Environmental
Temperature	Operating: 0°C to 40°C (32°F to 104°F) Non-operating and storage: −25°C to 70°C (−13°F to 158°F)
Humidity	Operating: 5% to 93% at 50°C (122°F) Non-operating and storage: 10% to 95% at 60°C (140°F)
Altitude	Operating: 0 to 3,000 m (9,842 ft.) Non-operating and storage: 0 to 12,000 m (39,370 ft.)
Shock	Operating: 15 G, 11 ms, half-sine wave Non-operating and storage: 33 G, 11 ms, half-sine wave, 5/ea axis, and 33 G 6 ms, trapezoidal, 1/ea axis
Vibration	Operating: 1 G sine, 0.5 gms random, 5 to 500 Hz Non-operating and storage: 2.4 G sine, 1.1 gms random, 5 to 500 Hz
Airflow	Maximum: 159 CMH (94 CFM) Minimum: 65 CMH (38 CFM)	Maximum: 370 CMH (218 CFM) Minimum: 95 CMH (56 CFM)
Power	VDX 6940-36Q	VDX 6940-144S
Power supplies	Two internal, redundant, field-replaceable, loadsharing power supplies	Two internal, redundant, field-replaceable, loadsharing power supplies
Power inlet	C13	C13
Input voltage	100 to 240 V or 48 V DC	100 to 240 V or 48 V DC
Input line frequency	50 to 60 Hz	50 to 60 Hz
Inrush current	30 A peak at cold start and 50 A peak at warm start for <10 ms, 10 A peak for cycles 10 ms to 150 ms, <7 A peak for >150 ms	40 A peak at either cold or warm start <10 ms, 10 A peak for cycles 10 ms to 150 ms, <7 A peak for >150 ms
Maximum current	6 A at 100 VAC 7 A at 90 VAC	6 A at 100 VAC 7 A at 85 VAC
Typical power consumption	At 100 VAC 2.18 A, 215 W, 733.81 BTU/hr At 200 VAC 1.12 A, 212 W, 723.57 BTU/hr Input current calculated with 1 PSU; watts and BTU/ hour with 2 PSUs	At 100 VAC 3.288 A, 327 W, 1,116 BTU/hr At 200 VAC 1.639 A, 321 W, 1,095 BTU/hr Input current calculated with 1 PSU; watts and BTU/ hour with 2 PSUs
Maximum power consumption	At 100 VAC 2.84 A, 282 W, 962.5 BTU/hr At 200 VAC 1.44 A, 276 W, 942 BTU/hr Input current calculated with 1 PSU; watts and BTU/ hour with 2 PSUs	At 100 VAC 2.706 A, 512 W, 1,747 BTU/hr At 200 VAC 1.375 A, 500 W, 1,706 BTU/hr Input current calculated with 1 PSU; watts and BTU/ hour with 2 PSUs
