SLX 9030 :: Other Switches :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme SLX 9030 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	SLX 9030-48S	SLX 9030-48T
Ports	48 1/10GbE SFP+ ports 4 10/40/100GbE QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out-of-band management port Micro-USB Type A storage port 25 GbE supported through break-outs	48 100 Meg, 1/10GbE 10GBaseT ports 4 10/40/100GbE QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out-of-band management port Micro-USB Type A storage port 25 GbE supported through break-outs
Power Supplies	Modular 770W AC power supply (up to two PSUs) Modular 1100W DC power supply (up to two PSUs) Front-Back and Back-Front airflow options	Modular 770W AC power supply (up to two PSUs) Modular 1100W DC power supply (up to two PSUs) Front-Back and Back-Front airflow options
Fan Modules	6 fan modules Front-Back and Back-Front airflow options	6fan modules Front-Back and Back-Front airflow options
Dimensions	17.4in W x 19.2in D x 1.7in H (44.1cm x 48.8cm x 4.3cm)	17.4in W x 19.2in D x 1.7in H (44.1cm x 48.8cm x 4.3cm)
Performance	Line rate 1.76Tbps Switching CapacityAverage Latency: 800 ns	Line rate 1.76Tbps Switching Capacity Average Latency: 2.3 μsec
CPU Memory	2.4GHz Quad core CPU 8GBE DDR3 ECC memory 32GBE SSD memory	2.4GHz Quad core CPU 8GBE DDR3 ECC memory 32GBE SSD memory
Packet Buffers	12MB	12MB
Operating Conditions	0º – 45ºC operation 10% to 95% relative humidity, non-condensing 0 – 3000 meters’ altitude Shock (half sine): 98 m/ s2 (10 G), 11ms, 9 shocks Random vibration: 3 to 500 Hz at 1.5 G rms	0º – 45ºC operation 10% to 95% relative humidity, non-condensing 0 – 3000 meters’ altitude Shock (half sine): 98 m/ s2 (10 G), 11ms, 9 shocks Random vibration: 3 to 500 Hz at 1.5 G rms
Power and Heat Dissipation
Minimum Heat Dissipation (BTU/hr) (Idle, no ports linked)	SLX 9030-48S AC: 282 BTU/ hr SLX 9030-48S DC: 311BTU/ hr	SLX 9030-48T AC: 425 BTU/ hr SLX 9030-48T DC: 421BTU/ hr
Minimum Power Consumption (Watts) (Idle, no ports linked)	SLX 9030-48S AC: 83 W SLX 9030-48S DC: 91W	SLX 9030-48T AC: 125 W SLX 9030-48T DC: 123 W
Maximum Heat Dissipation (BTU/hr) (Fans high, all ports 100% traffic)	SLX 9030-48S AC: 1124 BTU/ hr SLX 9030-48S DC: 1178 BTU/ hr	SLX 9030-48T AC: 1271BTU/ hr SLX 9030-48T DC: 1315 BTU/ hr
Maximum Power Consumption (Watts) (Fans high, all ports 100% traffic)	SLX 9030-48S AC: 329 W SLX 9030-48S DC: 345 W	SLX 9030-48T AC: 373 W SLX 9030-48T DC: 385 W
Acoustic Specifications
Bystander Sound Pressure	SLX 9030-48S (Front-Back Airflow): 55.4 dB(A) up to 30ºC 61.3 dB(A) up to 40ºC 76.8 dB(A) @ 45ºC (max) SLX 9030-48S (Back-Front Airflow): 56.9 dB(A) up to 30ºC 63.3 dB(A) up to 40ºC 77.4 dB(A) @ 45ºC (max)	SLX 9030-48T (Front-Back Airflow): 58 dB(A) up to 25ºC 72.8 dB(A) up to 35ºC 76.3 dB(A) @ 45ºC (max) SLX 9030-48T (Back-Front Airflow): 59.1dB(A) up to 25ºC 72.5 dB(A) up to 35ºC 77.5 dB(A) @ 45ºC (max)
Declared Sound Power	SLX 9030-48S (Front-Back Airflow): 6.9 bels up to 30ºC 7.5 bels up to 40ºC 9.0 bels @ 45ºC (max) SLX 9030-48S (Back-Front Airflow): 7.1 bels up to 30ºC 7.7 bels up to 40ºC 9.1bels @ 45ºC (max)	SLX 9030-48T (Front-Back Airflow): 7.2 bels up to 25ºC 8.7 bels up to 35ºC 9.0 bels @ 45ºC (max) SLX 9030-48T (Back-Front Airflow): 7.3 bels up to 25ºC 8.7 bels up to 35ºC 9.0 bels @ 45ºC (max)
