200 Series :: Other Switches :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme 200 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Category	Specifications
CPU/Memory	ARM Cortex-A9 32-bit processor, 400 MHz clock 512MB DRAM 128MB Flash 1.5MB MAC buffer; 128K L2 Cache (CPU)
Platform Specifications	Maximum MAC Addresses: 16,000 VLANs: Up to 1024 MSTP instances: 4 Link Access Groups (LAGs): 6 ACLs: 100 with 1023 rules per list Traffic Classes (Queues): 8
Core Switching Features	IEEE 802.1AB—Link Layer Discovery Protocol (LLDP) IEEE 802.1D—Spanning tree compatibility IEEE 802.1p—Ethernet priority with user provisioning and mapping IEEE 802.1s—Multiple spanning tree compatibility IEEE 802.1Q—Virtual LANs with port-based VLANs IEEE 802.1X—Port-based authentication with Guest VLAN support IEEE 802.1W—Rapid spanning tree compatibility IEEE 802.3—10BASE-T IEEE 802.3u—100BASE-T IEEE 802.3ab—1000BASE-T IEEE 802.1ak—Virtual Bridged Local Area Networks IEEE 802.3ac—VLAN tagging IEEE 802.3ad—Link aggregation IEEE 802.3at - PoE+ Power over Ethernet IEEE 802.3x —Flow control GARP—Generic Attribute Registration Protocol GMRP—Dynamic L2 multicast registration GVRP—Dynamic VLAN registration RFC 4541—Considerations for Internet Group Management Protocol (IGMP) Snooping Switches ANSI/TIA-1057—LLDP-Media Endpoint Discovery (MED) RFC 5171—Unidirectional Link Detection (UDLD) Protocol
Advanced Layer 2 Features	Authentication, Authorization, and Accounting (AAA) Broadcast/Multicast/Unknown unicast storm recovery DHCP Snooping IGMP Snooping Querier Multicast VLAN Registration (MVR) Industry Standard Discovery Protocol (CDP interoperability) IPv6 Classification APIs Jumbo Ethernet frame support Port MAC locking Port mirroring Protected ports Static MAC filtering Voice VLANs Unauthenticated VLAN Internal 802.1X Authentication Server 802.1X Monitor Mode 802.1X Client Scaling Link Dependency IPv6 RA Guard (Stateless) STP Loop Guard STP Root Guard BPDU Guard
Routing	IPv4 Static Routes (up to 60 routes) Provides basic routing through manual routing configuration
Quality of Service	Access Control Lists (ACLs) Time-Based ACL Source/Destination IP address TCP/UDP Source/Destination port IP Protocol Type Type of Service (ToS) or differentiated services (DSCP) field Source/Destination MAC address EtherType IEEE 802.1p user priority (outer and/ or inner VLAN tag) VLAN ID (outer and/or inner VLAN tag) RFC 1858—Security Considerations for IP Fragment Filtering Optional ACL Rule Attributes Assign flow to a specific Class of Service (CoS) queue Redirect matching traffic flows
Differentiated Services (DiffServ)	Classify traffic based on same criteria as ACLs and optionally: Mark the IP DSCP or Precedence header fields Police the flow to a specific rate with two-color aware support RFC 2474—Definition of the differentiated services field (DS field) in the IPv4 and IPv6 headers RFC 2475—An architecture for differentiated services RFC 2597—Assured forwarding Per-Hop Behavior (PHB) group RFC 2697—Single-rate policing RFC 3246—An expedited forwarding PHB RFC 3260—New terminology and clarifications for DiffServ
System Facilities	Event and error logging facility Run-time and configuration download capability PING utility Xmodem FTP Transfers via IPv4/IPv6 Malicious Code Detection TACACS+ RFC 768—UDP RFC 783—TFTP RFC 791—IP RFC 792—ICMP RFC 793—TCP RFC 826—ARP RFC 894—Transmission of IP datagrams over Ethernet networks RFC 896—Congestion control in IP/TCP networks RFC 951—BOOTP RFC 1034—Domain names - concepts and facilities RFC 1035—Domain names - implementation and specification RFC 1321—Message digest algorithm RFC 1534—Interoperability between BOOTP and DHCP RFC 2021—Remote network monitoring management information base version 2 RFC 2030—Simple Network Time Protocol (SNTP) RFC 2131—DHCP relay RFC 2132—DHCP options and BOOTP vendor extensions RFC 2819—Remote Network Monitoring Management Information Base RFC 2865—RADIUS client RFC 2866—RADIUS accounting RFC 2868—RADIUS attributes for tunnel protocol support RFC 2869—RADIUS Extensions RFC 3579—RADIUS support for EAP RFC 3580—IEEE 802.1X RADIUS usage guidelines RFC 3164—The BSD syslog protocol RFC 3580—802.1X RADIUS Usage Guidelines RFC 5176—Dynamic Authorization Server (Disconnect-Request processing only) RFC 5424—The Syslog Protocol
