X450-G2 :: Edge Switching :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Sophos SonicWall, ServerMonkey offers the X450-G2 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	X450-G2-48t-10GE4	X450-G2-48p-10GE4	X450-G2-48t-GE4	X450-G2-48p-GE4
Performance and Scale
Maximiu Active Gbe Ports	48	48	52	52
Maximiu Active 10Gbe Ports	4	4	0	0
21 Gbps Stacking Ports	2	2	2	2
Aggregated Switch Bandswitch*	260 Gbps	260 Gbps	188 Gbps	188 Gbps
Frame Forwarding Rate*	193.4 Mpps	193.4 Mpps	139.9 Mpps	139.9 Mpps
External Ports
External Ports	48 x 10/100/1000BASE-T (RJ-45) 4 x 10GBASE-X SFP+ (unpopulated ports) 1 x Serial (console port RJ-45) with RTS/CTS modem control 1 x 10/100/1000BASE-T out-of-band management port 1 x USB 2.0 port for external USB flash 2 dedicated QSFP-form factor 21Gbps stacking ports on the rear panel	48 x 10/100/1000BASE-T PoE-Plus 4 x 10GBASE-X SFP+ (unpopulated ports) 1 x Serial (console port RJ-45) with RTS/CTS modem control 1 x 10/100/1000BASE-T out-of-band management port 1 x USB 2.0 port for external USB flash 2 dedicated QSFP-form factor 21Gbps stacking ports on the rear panel	48 x 10/100/1000BASE-T (RJ-45) 4 x 1GBASE-X SFP (unpopulated ports) 1 x Serial (console port RJ-45) with RTS/CTS modem control 1 x 10/100/1000BASE-T out-of-band management port 1 x USB 2.0 port for external USB flash 2 dedicated QSFP-form factor 21Gbps stacking ports on the rear panel	48 x 10/100/1000BASE-T PoE-Plus 4 x 1GBASE-X SFP (unpopulated ports) 1 x Serial (console port RJ-45) with RTS/CTS modem control 1 x 10/100/1000BASE-T out-of-band management port 1 x USB 2.0 port for external USB flash 2 dedicated QSFP-form factor 21Gbps stacking ports on the rear panel
Physical
Dimension	Height: 1 RU / 1.73 inches (4.4 cm) Width: 17.4 inches (44.2 cm) Depth: 19.2 inches (48.8 cm)
Weight	14.22 lb (6.45 kg)	14.22 lb (6.45 kg)	14.51 lb (6.58 kg)	14.51 lb (6.58 kg)
Power
Minimum Heat Dissipation (BTU/HR)	178.1	238.8	178.1	238.8
Minimum Power Consumption (Watts)	52.2	70	52.2	70
Maximum Heat Dissipation (BTU/HR)	290	778 (@1440W PoE)	290	778 (@1440W PoE)
*Maximum Power Consumption (Watts)**	85	1668	85	1668
Non-PoE Switches
Voltage Input Range	100-240 VAC
Line Frequency Range	47 to 64 Hz
Power Supply Input Socket	IEC 320 C14
Power Cord Input Plug	IEC 320 C13
Operating Temperature	0° C to 50° C Normal Operation
