VSP 4900 :: Edge Switching :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Sophos SonicWall, ServerMonkey offers the VSP 4900 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	VSP4900- 12MXU-12XE	VSP4900-24XE	VSP4900-24S	VSP4900-48P
Performance and Scaling
Max Active 10/100/ 1000Mb Ports	N/A	0	0	48
Max Active 100M/1Gb/ 2.5Gb/5Gb/ 10Gb Ports	12	0	0	0
Max Active 100M/1Gb SFP ports	0	24	0	0
Max Active 1/10Gb SFP+ ports	16	28	4	4
Max Active 10/ 25Gb SPF28 ports	4	4	2	2
Max Active 40Gb QSFP+ ports*	2	2	1	1
Aggregated Switch Bandwidth	680 Gbps	680 Gbps	148 Gbps	196 Gbps
Frame Forwarding Rate	505.9 Mpps	505.9 Mpps	110.1 Mpps	145.8 Mpps
External Ports/Slot
Ports/Slots	12 x 1/2.5/5/10GBASE-T 802.3bt Type3 (60w) ports 12 x 1/10GBASE-X SFP+ ports (unpopulated) MACsec capable (256-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	24 x 1/10GBASE-X SFP+ ports (unpopulated) LRM and MACsec capable (256-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	24 x 100/1000BASE-X SFP ports (unpopulated) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot	48 x 10/100/1000BASE-T 802.3at (30w) ports Full / Half-Duplex MACsec capable (128-bit) 1 x Serial (console port RJ-45) 1 x 10/100/1000BASE-T out-of-band management port 1 x USB Micro-B management port 2 x USB A ports for external USB flash 1 VIM5 slot
VIM Modules
VIM Modules	VIM5-4X: 4 x 1/10GBASE-X SFP+ (unpopulated ports) VIM5-4XE: 4 x 1/10GBASE-X SFP+ (unpopulated ports) LRM capable MACsec capable (256-bit) VIM5-2Y: 2 x 10/25GBASE-X SFP28 (unpopulated ports) VIM5-4Y: 4 x 10/25GBASE-X SFP28 (unpopulated ports) VIM5-4YE: 4 x 10/25GBASE-X SFP28 (unpopulated ports) MACsec capable (256-bit) VIM5-2Q: 2 x 40GBASE-X QSFP+ (unpopulated ports)
Physical Specifications
Dimensions	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm	17.34 in W / 1.7 in H / 19.23 in D 440mm / 43.6mm / 488mm
Net Weight	16.67 lb / 7.58 kg	16.89 lb / 7.66 kg	18.01 lb / 8.17 kg	18.49 lb / 8.39 Kg
Minimum/Maximum Power Consumption and Heat Dissipation
Minimum Power Consumption (Watts)	73	80	52	74
Minimum Heat Dissipation (BTU/hr)	250	271	179	254
Maximum Power Consumption (Watts)¹	970	207	173	1746
Maximum Heat Dissipation (BTU/hr)²	854	707	590	1046
