V400 Series :: Edge Switching :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme V400 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	V400-24t-10GE2	V400-24p-10GE2	V400-48t-10GE4	V400-48p-10GE4
Ports	24 x 10/100/1000BASE-T (RJ-45) Half, Full, Auto Duplex 2 x 10GBASE-X SFP+ 1 x Serial (console port RJ-45) USB	24 x 10/100/1000BASE-T (RJ-45) PoE-Plus Half, Full, Auto Duplex 2 x 10GBASE-X SFP+ 1 x Serial (console port RJ-45) USB RPS port	48 x 10/100/1000BASE-T (RJ-45) Half, Full, Auto Duplex 4 x 10GBASE-X SFP+ 1 x Serial (console port RJ-45) with RTS/CTS modem control USB	48 x 10/100/1000BASE-T (RJ-45) PoE-Plus Half, Full, Auto Duplex 4 x 10 GBASE-X SFP+ 1 x Serial (console port RJ-45) with RTS/CTS modem control USB RPS port
Performance and Scale
Maximum 10/100/1000 Base-T Ports	24	24	48	48
Maximum Active 1Gb SFP ports	2*	2	4	4
Maximum Active 10Gb SFP+ Ports	0	2	4	4
Aggregated Switch Bandwidth	40 Gbps	40 Gbps	80 Gbps	80 Gbps
Frame Forwarding Rate	59 Mpps	59 Mpps	119 Mpps	119 Mpps
Physical
Dimensions	1RU / 1.70 inches (4.32 cm) H 17.34 inches (44.0 cm) W 9.97 inches (25.3 cm) D	1RU / 1.70 inches (4.32 cm) H 17.34 inches (44.0 cm) W 9.97 inches (25.3 cm) D	1RU / 1.70 inches (4.32 cm) H 17.34 inches (44.0 cm) W 9.97 inches (25.3 cm) D	1RU / 1.70 inches (4.32 cm) H 17.34 inches (44.0 cm) W 15.25 inches (38.7 cm) D
Weight	6.62 lb (3.0 0 kg)	9.0 8 lb (4.12 kg)	7.18 lb (3.26 kg)	14.0 6 lb (6.38 kg)
Power and Heat Dissipation
Minimum¹ Heat Dissipation (BTU/ HR)	7.2	3.3	7.6
Maximum¹ Power Consumption (Watts)	129.1	7.0	214.6
Maximum² Heat issipation (BTU/ HR)	82.1	23.8	118.2
Maximum²Power Consumption (Watts)	82.1	23.8	118.2
PoE Power Budget
Power Supply		380 W		*380 W
Max PoE Budget		740 W		*740 W
Fan and Acoustic Noise
Acoustic Information Bystander Sound Pressure	41.6 (Dut y 30 %) / 59.4 (max.)	47.5 (Dut y 30 %) / 64.0 (max.)	43.4 (Dut y 30 %) / 61.1(max.)	4.6 (Dut y 30 %) / 6.4 (max.)
Declared Sound Power (LWAD)*	4.4 (Dut y 30 %) / 6.2 (max.)	5.0 (Dut y 30 %) / 6.7 (max.)	48.5 (Dut y 30 %) / 65.5 (max.)	5.1(Dut y 30 %) / 6.8 (max.)
