Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Sophos SonicWall, ServerMonkey offers the ERS 3600 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

ERS 3626GTS Specifications
Hardware Summary
General	Physical Connectivity: 1000BASE-T Access Ports (supporting both Half- and Full-Duplex) 1000BASE-SFP Combo Network Uplink Ports 10GBASE-SFP+ Network Uplink Ports Switching Fabric: 128Gbps (Full-Duplex) for 26-port models Frame Forwarding: 95Mpps for 26-port models Nominal Latency: 3.5 microseconds for 64 Byte packets Nominal Jitter: 0.84 microseconds for 64 Byte packets Frame Length: 64 to 1518 Bytes (Untagged), 64 to 1522 Bytes (Tagged) Jumbo Frame: up to 9,216 Bytes (802.1Q Tagged) Stackable Chassis Throughput: 24Gbps (Full-Duplex) per Switch, up to 192Gbps
Layer 2	MAC Address: up to 16,384 Port-based VLANs: 256 MSTP Instances: 8 MLT/LACP Groups: 6 Links per MLT/LACP Group: 4 DHCP Snooping Entries: up to 512 802.1X Clients: 32 per Port LLDP Neighbors: up to 816
Layer 3 IPv4 Routing Services	ARP Entries: up to 512 Static ARP Entries: up to 256 IP Interfaces: up to 64 IP Routes: up to 256 IP Static Routes: up to 32 IP Route Policies: up to 64 RIP Interfaces: up to 16 RIP Routes: up to 256
Layer 3 IPv6 Routing Services	IPv6 Interfaces: 256 IP Routes: up to 2,048 IPv6 Static Neighbors: 256 CLIP Interfaces: 16 IPv6 Management Tunnels: 4 IPv6 Data Tunnels: 8 IPv4/IPv6 Dual Stack Router Advertisement Guard DHCPv6 Guard MLDv1/v2 Snooping Duplicate Address Detection and Snooping Neighbor Unreachability Detection and Filtering
Multicast	IGMP Enabled VLANs: 256 IP Multicast Groups: up to 248
QoS and Filtering	QoS Precedences: 8 QoS Filters per Switch: 256 per Precedence
Operations and Management	Port Mirroring Instances: 1, Many-to-One supported RMON Entries per Port: 4 Groups Auto-MDIX Detection Enterprise Device Manager GUI, on-box & off-box
Support Transceivers	10GBASE-LRM SFP+ (AA1403017-E6), up to 220m over FDDI-grade MMF 10GBASE-SR/SW SFP+ (AA1403015-E6), up to 300m over MMF 10GBASE-LR/LW SFP+ (AA1403011-E6), up to 10km over SMF 10GBASE-ER/EW SFP+ (AA1403013-E6), up to 40km over SMF 10GBASE-ZR/ZW SFP+ (AA1403016-E6), up to 80km over SMF 10GBASE-CX (AA1403019-E6)* Dual-Attach Cable, up to 3m over Twinax 10GBASE-CX (AA1403020-E6)* Dual-Attach Cable, up to 5m over Twinax 10GBASE-CX (AA1403018-E6)* Dual-Attach Cable, up to 10m over Twinax
Physical Specifications
Dimensions	17.3 in (W) x 1.7 in (H) x 11.0 in (D) 440 mm x 44 mm x 280 mm
Weight	3.5-6.3 kg
Power Specifications
	ERS 3626GTS Up to 24.78W, up to 0.24A, and up to 84.55BTU/hr @ 200-240VAC Up to 24.60W, up to 0.42A, and up to 83.94BTU/hr @ 100-110VAC 14.82W power consumption at idle, and 18.28W under typical traffic load ERS 3626GTS-PWR+ Up to 828.69W, up to 3.66A, and up to 360.61BTU/hr @ 200-240VAC Up to 874.92W, up to 7.05A, and up to 518.35BTU/hr @ 100-110VAC 26.66W power consumption at idle, and 30.17W under typical traffic load (excluding PoE draw)
Environmental Specifications
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Operating Humidity	0 to 95% maximum relative humidity, non-condensing
Storage Humidity	10 to 90% maximum relative humidity, non-condensing
Operating Altitude	0 to 3,048m (0 to 10,000ft) maximum
Storage Altitude	0 to 12,192m (0 to 40,000ft) maximum
Acoustic Noise	Less than 47dbA at 25°C Less than 55dbA at 50°C
Safety Agency Approvals	IEC 60950 International CB Certification EN 60950-1 Europe Safety (CE): CB Scheme Certification with Member Deviations UL 60950-1 USA Safety CSA-C22.2, #60950-1 Canada Safety NOM Mexico Safety EN 60950-1 Japan Safety Anatel Brazilian Safety ACMA-RCM Australia Safety Customs Union/EAC Safety of Low-Voltage Equipment Certification CCC & MIIT China Safety CNS 14336-1 Taiwan BSMI Safety UL 1069 Hospital Signaling and Nurse Call Equipment (relevant to PWR units only)
Electromagnetic Emissions and Immunity	CISPR 22 International EMC Emissions CIRPR 24 International EMC Immunity FCC part 15B, Class A USA EMC Emissions ICES-003 Class A Canadian EMC Emissions VCCI Japan EMC Emissions EN 55022 Class A, CISPR 22 European EMC Emissions (CE) EN 55024, CISPR 24 including EN 61000-4-2, 4-3, 4-4, 4-5, 4-6, 4-8 & 4-11 European EMC Immunity (CE) ACMA-RCM Mark Australia EMC Emissions Anatel Brazilian EMC Certification Customs Union/EAC EMC Certification CCC & MIIT China EMC Certification KC mark: EMI & EMS Korean EMC Certification CNS 13438 Taiwan BSMI EMC
MTBF Values	ERS 3626GTS – 336,851 hours (38.45 years) ERS 3626GTS-PWR+ – 136,469 hours (15.57 years)
