Details:

Description

	X590-24x-1q-2c	X590-24t-1q-2c
Ports	24 1Gb/10Gb SFP+ ports 1 10Gb/40Gb QSFP+ ports 2 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out-of-band management port Micro-USB Type A storage port Selectable QSFP Port Configurations 1 10Gb/40Gb QSFP+ and 2 100Gb QSFP28 SummitStack-V400 stacking ports or 2 10Gb/25Gb/40Gb/ 50Gb/100Gb QSFP28 (1QSFP+ port inactive)	24 100Mb/1Gb/10Gb 10GBASE-T ports 1 10Gb/40Gb QSFP+ ports 2 10Gb/25Gb/40Gb/50Gb/100Gb QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out-of-band management port Micro-USB Type A storage port Selectable QSFP Port Configurations 1 10Gb/40Gb QSFP+ and 2 100Gb QSFP28 SummitStack-V400 stacking ports or 2 10Gb/25Gb/40Gb/ 50Gb/100Gb QSFP28 (1QSFP+ port inactive)
Power Supplies	Modular 770W AC power supply (up to two PSUs) Modular 1100W DC power supply (up to two PSUs) Front-Back and Back-Front airflow options	Modular 770W AC power supply (up to two PSUs) Modular 1100W DC power supply (up to two PSUs) Front-Back and Back-Front airflow options
Fan Modules	4 fan modules Front-Back and Back-Front airflow options	4 fan modules Front-Back and Back-Front airflow options
Dimensions	17.4in W / 19.2in D / 1.7in H (44.1cm / 48.8cm / 4.3cm)	17.4in W / 19.2in D / 1.7in H (44.1cm / 48.8cm / 4.3cm)
Performance	880Gbps Switching Capacity / 714Mpps Forwarding Rate	880Gbps Switching Capacity / 714Mpps Forwarding Rate
CPU Memory	2.4GHz Quad core CPU 4GB DDR3 ECC memory 32GB SSD memory	2.4GHz Quad core CPU 4GB DDR3 ECC memory 32GB SSD memory
Packet Buffers	12MB	12MB
MTBF	435,074 hours	337,871hours
Operating Conditions	0 º - 45ºC operation 10 % to 95% relative humidity, non-condensing 0 - 3000 meters altitude Shock (half sine): 98 m/ s2 (10 G), 11ms, 9 shocks Random vibration: 3 to 500Hz at 1.5 G rms
Power and Heat Dissipation
Minimum Heat Dissipation (BTU/hr) (Idle, no ports linked)	AC: 278.42 BTU/hr DC: 286.61 BTU/hr	AC: 310.97 BTU/hr DC: 332.63 BTU/hr
Minimum Power Consumption (Watt s) (Idle, no ports linked)	AC: 81.60 W DC: 84.00 W	AC: 91.14 W DC: 97.49 W
Maximum Heat Dissipation (BTU/hr) (Fans high, all ports 100% traffic)	AC: 743.82 BTU/hr DC: 786.12 BTU/hr	AC: 792.27 BTU/hr DC: 833.62 BTU/hr
Maximum Power Consumption (Watts) (Fans high, all ports 100% traffic)	AC: 218.00 W DC: 230.40 W	AC: 232.20 W DC: 244.32 W
Acoustic Specifications
Bystander Sound Pressure (Front-Back Airflow)	55.6 dB(A) up to 30 ºC 57.8 dB(A) up to 40 ºC 79.8 dB(A) @ 45ºC (max)	54.7 dB(A) up to 25ºC 61.9 dB(A) up to 35ºC 79.4 dB(A) @ 45ºC (max)
Bystander Sound Pressure (Back-Front Airflow)	55.8 dB(A) up to 30 ºC 57.9 dB(A) up to 40 ºC 79.1dB(A) @ 45ºC (max)	55.5 dB(A) up to 25ºC 62.6 dB(A) up to 35ºC 79.7 dB(A) @ 45ºC (max)
Declared Sound Power (Front-Back Airflow)	6.9 bels up to 30 ºC 7.1 bels up to 40 ºC 9.5 bels @ 45ºC (max)	6.8 bels up to 25ºC 7.6 bels up to 35ºC 9.4 bels @ 45ºC (max)
Declared Sound Power (Back-Front Airflow)	6.9 bels up to 30 ºC 7.1 bels up to 40 ºC 9.5 bels @ 45ºC (max)	6.8 bels up to 25ºC 7.5 bels up to 35ºC 9.2 bels @ 45ºC (max)
