SLX 9240 :: Core/Data Center Switching :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme 9240 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

	SLX 9240 Switch Specifications
Form Factor	1U
Switching Bandwidth (data rate, full duplex)	3.2 Tbp in and 3.2 Tbps out for a sum total of 6.4 Tbps
Forwarding Capacity (data rate, full duplex)	(L2) 2.4 Bpps, (L3) 600 Mpps line-rate performance
Dimensions and Weight	440 mm; 17.32 in. (Width), 444.7 mm; 17.5 in. (Depth) 43.7mm; 1.72 in. (Height) 9.07 kg; 20 lb
Port-to-port latency	2.5 usec
Architecture Store and Forward	Supported
100/40 GbE Ports	32
Power Supplies	Two internal, redundant, field-replaceable, load-sharing AC or DC power supplies
Cooling Fans	Five field-replaceable fans
Dynamically Shared Packer Buffer	24 MB
Power
Power Inlet (AC)	C13
Input Voltage	90 V to 264 V or 40.8 V to 60 V DC
Input Line Frequency	47 Hz to 63 Hz
Inrush Current	25 A peak
Maximum Current	12 A/AC, 14 A/D
Typical Power Consumption	84 W \| Two AC PSU, five fan trays, 10% traffic, low fan speed
Maximum Power Consumption	581 W \| Two AC PSU, six fan trays, 100% traffic, high fan speed
Power Supply Rated Maximum (AC)	650 W
Switch Power Consumption	DC PSU 563 W; AC PSU 581 W
Environment
Humidity	5% to 95% at 50°C
Altitude	Up to 3,000 m safety; 60 m to 4,000 m operational
Shock (operational)	20 G, 11 ms, half-sine wave
Vibration (operational)	1 G sine, 0.4 gms random, 5 Hz to 500 Hz
Airflow	134 CFM (estimated with two PSU, six fan trays)
Acoustics (25°C)	52 dBA
MTBF (25°C)	327,539 hours
Software Specifications
Connector Options	10 GbE SFP+ (via splitter cable) 100 GbE QSFP-28 40 GbE QSFP+ Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45 Console management: RJ45 serial port and USB type-C port with serial communication device class support Storage: USB port, standard-A plug
Maximum MAC Addresses	Up to 48,000
Maximum VLANs	4,096
Maximum Routes (in hardware)	Up to 40,000
Maximum ACLs	512
Maximum Members in a Standard LAG	16
Maximum Per-Port Priority Pause Level	8
Maximum Switches an mLAG Can Span	2
Maximum IPv4 Unicast Routes	48,000
Maximum IPv6 Unicast Routes	8,000
DCB Priority Flow Control Classes	4
Maximum Jumbo Frame Size	10,000 bytes
QoS Priority Queues (per port)	8
