8250 Series :: Core/Data Center Switching :: Switches :: Extreme :: Networking

Their next-generation firewalls provide visibility, security, and control to help you manage your business, no matter the size. SonicWall firewalls are designed to match your security needs and protect your budget. Their secure wireless access points enhance the user experience by improving performance, range, and visibility. Lastly, their high-speed switching provides secure connectivity for the modern business.

As a trusted Extreme, ServerMonkey offers the Extreme 8250 Series competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Model	8520-48Y	8520-48XT
Ports	48 1/10/25GbE SFP28 ports 8 40/100GbE QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out -of-band management port USB Type A storage port	48 1/10GbE 10GBaseT ports 6 40/100GbE QSFP28 ports 1x Serial console port RJ-45 1x 10/100/1000BASE-T out -of-band management port USB Type A storage port
Power Supplies	Modular 750W AC power supply (up to two PSUs) Modular 750W DC power supply (up to two PSUs) Front to Back and Back to Front airflow options	Modular 750W AC power supply (up to two PSUs) Modular 750W DC power supply (up to two PSUs) Front to Back and Back to Front airflow options
Fan Modules	6 fan modules Front -Back and Back-Front airflow options	6 fan modules Front -Back and Back-Front airflow options
Dimensions	17.3in W / 21.24in D / 1.7in H (44.0cm / 53.95cm / 4.3cm)	17.3in W / 21.24in D / 1.7in H (44.0cm / 53.95cm / 4.3cm)
Performance	Line rate 4Tbps Switching Capacity (2Tbps ingress, 2Tbps egress) Average Latency: 800 ns Forwarding rate: 1000 Mpps	Line rate 2.16 Tbps Switching Capacity (1.08Tbps ingress, 1.08Tbps egress) Average Latency: 2,400 ns Forwarding rate: 1000 Mpps
CPU Memory	8-core Processor 16GB DDR4 ECC memory 128GB SSD memory	8-core Processor 16GB DDR4 ECC memory 128GB SSD memory
Packet Buffers	32MB	32MB
Operating Conditions	AC/DC, one fan failed, front-to-back: 0°C (32°F) to 50°C (122°F) at sea level; 0°C (32°F) to 40°C (104°F) up to 3000 m (10,000 ft)	AC/DC, one fan failed, back-to-front: 0°C (32°F) to 45°C (113°F) at sea level; 0°C (32°F) to 40°C (104°F) up to 3000 m (10,000 ft)
