XR600P :: Routing :: Extreme :: Networking

Extreme Networks helps you optimize your network by providing infinite distribution of secure connectivity wherever your users are. Their networking solutions focus on providing the best application experience for customers and equipping them with the capabilities and insights they require. ExtremeSwitching makes every connection effortless,

As a trusted Extreme, ServerMonkey offers the Extreme XR600P competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Interfaces
Compliance	IEEE 802.3ab (1000BASE-T), 802.3u (1000BASE-TX), 802.3 (10BASE-T)
Ports	6x 1GE ports 2x WAN (WAN0 and WAN1), WAN1 can be configured as LAN port 4x LAN (one can be configured as WAN port, 3x WAN ports total) 4x PoE ports with 60W power budget, supporting 4x IEEE 802.3af PoE, 2x 802.3at PoE+ or other combinations 1x USB 2.0 port and 1x USB 3.0 port with backward compatibility with USB 1.1 (1 side, 1 rear) 1x RJ45 console port 1x Reset button
Modem Support	Skyus DS (Global) U620L (Verizon) ConnectedIO (LT1000) Huawei UMG366 (ATT and T-Mobile) Pantech UML290 (Verizon)
Performance
Firewall Throughput	Up to 600 Mbps
VPN Throughput	Up to 250 Mbps
Optimization and Detection	Multi-path optimization and link-state detection
Security
VPN Modes	VPN Server Mode (Layer 3 IPsec) VPN Client Mode (Layer 3 IPsec) with virtual gateway tunnel terminator
Additional Security Features	URL Filtering Wired authentication including 802.1X, MAC authentication, and Captive Web Portal support Identity-based access control plus application visibility for 1200+ apps Stateful firewall Full Trusted Computing Group (TCG) Trusted Platform Module (TPM)
Mounting
Options	Desktop, Wall mount, Optional rack mount key for 1u rack
Physical
Dimensions	8.7” W x 1.14” H x 6.3” D (22 cm W x 2.9 cm H x 16 cm D)
Weight	1.2 lb (544.31g)
Environmental
Operating Temperature	32 °F to 104 °F (-0 to 40 °C)
Storage Temperature	-40 °F to 176 °F (-40 to 80 °C)
Operating Humidity	10% to 90% RH (noncondensing)
MTBF	350,000 Hours at 25ºC
Power
AC Power Adapter	Input: 100 – 240 VAC, Output: 54V/1.67A, 90.18W
PoE	802.3af DC power up to 12.95W 802.3at DC power up to 25.5W
Physical Security
Security Slot	1 Kensington Security Slot
