Extreme Networks helps you optimize your network by providing infinite distribution of secure connectivity wherever your users are. Their networking solutions focus on providing the best application experience for customers and equipping them with the capabilities and insights they require. ExtremeSwitching makes every connection effortless,

As a trusted Extreme, ServerMonkey offers the Extreme CER 2000 competitive rates, providing businesses with access to top-tier networking hardware.

Request a Quote

Details:

Description

Comprehensive IPv4/IPv6 Routing Support (ExtremeRouting Neltron OS)
Routing Features	High-performance, robust routing using Forwarding Information Base (FIB) programming in hardware RIP/RIPng, OSPF/OSPFv3, IS-IS/IS-IS for IPv6, and BGP-4/BGP-MP for IPv6 Secure Multi-VRF routing for supporting virtual routing applications over non-MPLS backbones VRRP and VRRP-E 8-path Equal Cost Multi-Path (ECMP) Up to 1,500,000 IPv4 unicast routes in FIB Up to 256,000 IPv6 unicast routes in FIB Connecting IPv6 islands over IPv4 MPLS using IPv6 Provider Edge (6PE) routers 6VPE enabling IPv6 multitenancy to the edge of the cloud BFD Holdover for OSPFv2/3 and IS-IS BFD for Static Routes BFD for OSPFv3 ND6 IPv6 Prefix Suppress IS-IS Graceful Restart Helper Mode 127-bit IPv6 interface addresses
Software-Defined Networking (SDN)
OpenFlow 1.3 Features	QoS (for metering and enqueue), Group Table (select and fast failover) Q-in-Q (TAG type auto-recognition) Active-Standby Controller, IPv6, Transport Layer Security (TLS) 1.2 (controller interface)
Extreme Hybrid Switch Mode OpenFlow	Supports up to 32,000 OpenFlow flows
Rich Multicast Support
IPv4 Multicast Protocols	PIM-DM, PIM-SM, and PIM-SSM
IPv6 Multicast Support	PIM-SM/SSM and MLD
IGMP	v2/v3 routing and snooping support
Additional Multicast Features	IGMP static group support Multicast boundaries to facilitate admission control PIM and MLD snooping for IPv6 Up to 6000 multicast groups in hardware Multicast traffic distribution over Link Aggregation Groups (LAGs) Efficient egress interface-based replication to maximize performance and conserve buffers Multicast for MPLS Multicast ECMP
Advanced MPLS Features
MPLS Signaling and Path Calculation	OSPF-TE, IS-IS-TE, RSVP-TE, and CSPF
MPLS Protection	MPLS Fast ReRoute (FRR) and hot standby paths
Label Distribution Protocol (LDP)	Advanced MPLS services: IP over MPLS, VLL, VPLS, Layer 3 VPN, and routing over VPLS
BFD for RSVP-TE LSPs	LDP Inbound and Outbound FEC Filtering
Additional MPLS Features	RSVP Liberal Bypass LSP Selection Link Protection Request for RSVP Fast Reroute RSVP Hello Messages for Neighbor Failure Detection RSVP TE Link Metric for CSPF Computation Static Route over RSVP LSP
Advanced Carrier-Grade Ethernet Services
MAC Addresses	Up to 128,000
VLANs/S-VLANs/B-VLANs	Up to 4000
Ethernet Service Instance (ESI) Framework	Ability to reuse VLAN-ID on each port
MPLS Layer 2 VPN Services	IEEE 802.1ad Provider Bridges, IEEE 802.1ah Provider Backbone Bridges
Fault Management	IEEE 802.1ag Connectivity Fault Management, ITU Y.1731 OAM functions and mechanisms
Layer 2 Control Protocols	Extreme MRP/MRP-II, VSRP, RSTP, MSTP, and ITU G.8032 Ethernet Ring Protection (ERP v1 and 2)
Multi-Chassis Trunking (MCT)	Support for up to 256 clients (Active/Active mode or Active/Standby mode for Active/Passive access for client ports)
MEF Certification	MEF 9, MEF 14, and MEF 21 certification
Link Aggregation
IEEE 802.3ad LACP or Static Trunks	Up to 12 ports per LAG
LACP	Support for single-link Link Aggregation Control Protocol (LACP)
Buffering	64 to 192 MB of buffering, based on configuration
Advanced QoS
Traffic Policing	Inbound and outbound two-rate, three-color traffic policers with accounting
Queue Servicing Disciplines	Strict Priority, Weighted Fair Queuing, and hybrid
Remarking Capabilities	Based on port, VLAN, PCP, DSCP, or IPv4 flow
Shaping	Egress port and priority-based shaping
QoS for Management Protocols	QoS for SSH and Telnet
Comprehensive Hardware-Based Security and Policies
ACLs	Hardware-based Layer 3 and Layer 2 ACLs (both inbound and outbound) with logging
Port Security	Port-based network access control using 802.1x or MAC port security
Guard Capabilities	Root guard and BPDU guard
Rate Limits	Broadcast, multicast, and unknown unicast rate limits
ARP Inspection	ARP inspection for static entries
Static ARP and MAC	Multi-port static ARP and static MAC
Advanced Monitoring Capabilities
Mirroring	Port- and ACL-based mirroring based on incoming port, VLAN-ID, or IPv4/TCP/UDP flow
sFlow Sampling	Hardware-based sFlow sampling for extensive Layer 2-7 traffic monitoring
sFlow Support	sFlow support for MPLS LSR and LER interfaces
Interface Capabilities
Jumbo Frame Support	Support for frames up to 9216 bytes
Optical Monitoring	Monitoring of SFP and XFP optics for fast detection of fiber faults
Link Fault Support	UDLD and LFS/RFN support
Redundancy
Power Supplies	Redundant, hot-swappable AC/DC power supplies
Fan Tray	Removable fan tray with fan redundancy
