Radio type

2.4 GHz: 802.11b/g/n, 2x2 MIMO, 2 spatial streams

5 GHz: 802.11a/n/ac, 2x2 MIMO, 2 spatial streams

802.11ac Wave 2 capabilities

802.11n Version 2.0 (and related) capabilities

Data rates supported

2.4-GHz radio:

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n data rates:

MCS index

GI = 800 ns

20-MHz rate (Mbps)

GI = 400 ns

20-MHz rate (Mbps)

0

6.5

7.2

1

13

14.4

2

19.5

21.7

3

26

28.9

4

39

43.3

5

52

57.8

6

58.8

65

7

65

72.2

8

13

14.4

9

26

28.9

10

39

43.3

11

52

57.8

12

78

86.7

13

104

115.6

14

117

130

15

130

144.4

5-GHz radio:

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n data rates:

MCS index

GI = 800 ns

20-MHz rate (Mbps)

GI = 400 ns

20-MHz rate (Mbps)

GI = 800 ns

40-MHz rate (Mbps)

GI = 400 ns

40-MHz rate (Mbps)

0

6.5

7.2

13.5

15

1

13

14.4

27

30

2

19.5

21.7

40.5

45

3

26

28.9

54

60

4

39

43.3

81

90

5

52

57.8

108

120

6

58.8

65

121.5

135

7

65

72.2

135

150

8

13

14.4

27

30

9

26

28.9

54

60

10

39

43.3

81

90

11

52

57.8

108

120

12

78

86.7

162

180

13

104

115.6

216

240

14

117

130

243

270

15

130

144.4

270

300

802.11ac data rates:

MCS index

Spatial streams

20-MHz rate (Mbps)

40-MHz rate (Mbps)

80-MHz rate (Mbps)

GI = 800 ns

GI = 400 ns

GI = 800 ns

GI = 400 ns

GI = 800 ns

GI = 400 ns

0

1

6.5

7.2

13.5

15

29.3

32.5

1

1

13

14.4

27

30

58.5

65

2

1

19.5

21.7

40.5

45

87.8

97.5

3

1

26

28.9

54

60

117

130

4

1

39

43.3

81

90

175.5

195

5

1

52

57.8

108

120

234

260

6

1

58.5

65

121.5

135

263.3

292.5

7

1

65

72.2

135

150

292.5

325

8

1

78

86.7

162

180

351

390

9

1

-

-

180

200

390

433.3

0

2

13

14.4

27

30

58.5

65

1

2

26

28.9

54

60

117

130

2

2

39

43.3

81

90

175.5

195

3

2

52

57.8

108

120

234

260

4

2

78

86.7

162

180

351

390

5

2

104

115.6

216

240

468

520

6

2

117

130

243

270

526.5

585

7

2

130

144.4

270

300

585

650

8

2

156

173.3

324

360

702

780

9

2

-

-

360

400

780

866.7

Frequency band and 20-MHz operating channels

A (A regulatory domain):

B (B regulatory domain):

C (C regulatory domain):

D (D regulatory domain):

E (E regulatory domain):

F (F regulatory domain):

G (G regulatory domain):

H (H regulatory domain):

I (I regulatory domain):

K (K regulatory domain):

L (L regulatory domain):

M (M regulatory domain):

N (N regulatory domain):

Q (Q regulatory domain):

R (R regulatory domain):

S (S regulatory domain):

T (T regulatory domain):

Z (Z regulatory domain):

Note: Customers are responsible for verifying approval for use in their individual countries. Not all regulatory domains are available for the ESW6300. To verify approval and to determine availability of the regulatory domain that corresponds to a particular country, visit https://www.cisco.com/c/dam/assets/prod/wireless/wireless-compliance-tool/index.html.

Maximum number of nonoverlapping channels

2.4 GHz

◦      20 MHz: 3

◦      20 MHz: 3

◦      40 MHz: 1 (hardware-capable)

5 GHz

◦      20 MHz: 27

◦      20 MHz: 27

◦      40 MHz: 13

◦      20 MHz: 27

◦      40 MHz: 13

◦      80 MHz: 6

Note: This number varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.

Receive sensitivity

2.4-GHz radio, 20-MHz channel bandwidth

802.11b

Data rate (Mbps)

Typical sensitivity (dBm)

1

-97

2

-94

5.5

-90

11

-87

802.11g

Data rate (Mbps)

Typical sensitivity (dBm)

6

-89

9

-89

12

-87

18

-85

24

-83

36

-80

48

-75

54

-74

802.11n HT20

MCS index

Spatial streams

Typical sensitivity (dBm)

0

1

-89

1

1

-89

2

1

-87

3

1

-85

4

1

-83

5

1

-80

6

1

-75

7

1

-74

8

2

-88

9

2

-85

10

2

-83

11

2

-80

12

2

-76

13

2

-72

14

2

-71

15

2

-69

5-GHz radio

802.11a

Data rate (Mbps)

Sensitivity (dBm)

6

-90

9

-88

12

-87

18

-84

24

-81

36

-77

48

-75

54

-74

802.11n/ac

MCS index

Spatial streams

Typical sensitivity, HT/VHT20 (dBm)

Typical sensitivity, HT/VHT40 (dBm)

Typical sensitivity, VHT80 (dBm)

0

1

-90

-87

-84

1

1

-88

-86

-83

2

1

-87

-84

-82

3

1

-84

-81

-79

4

1

-81

-78

-76

5

1

-77

-74

-72

6

1

-75

-73

-70

7

1

-74

-71

-68

8

1

-69

-67

-64

9

1

-

-65

-62

0

2

-89

-86

-84

1

2

-86

-84

-81

2

2

-83

-82

-78

3

2

-80

-78

-74

4

2

-77

-75

-71

5

2

-73

-70

-67

6

2

-71

-68

-65

7

2

-70

-67

-64

8

2

-65

-62

-59

9

2

-

-60

-58

Maximum conducted transmit power

2.4-GHz radio: 27 dBm with 2 antennas at all data rates

5-GHz radio

802.11a

Data rate (Mbps)

Maximum conducted transmit power with two antennas (dBm)

6

27

9

27

12

27

18

27

24

26

36

26

48

25

54

24

802.11n/ac

MCS index

Spatial streams

Maximum conducted transmit power with two antennas (dBm)

20-MHz bandwidth

40-MHz bandwidth

80-MHz bandwidth

HT/VHT MCS0

1

27

27

27

HT/VHT MCS1

1

27

27

27

HT/VHT MCS2

1

27

27

27

HT/VHT MCS3

1

27

27

27

HT/VHT MCS4

1

26

26

26

HT/VHT MCS5

1

25

25

25

HT/VHT MCS6

1

24

24

25

HT/VHT MCS7

1

23

23

23

VHT MCS8

1

23

23

23

VHT MCS9

1

-

22

22

HT MCS8/VH MCS0

2

27

27

27

HT MCS9/VH MCS1

2

27

27

27

HT MCS10/VH MCS2

2

27

27

27

HT MCS11/VH MCS3

2

27

27

27

HT MCS12/VH MCS4

2

25

25

25

HT MCS13/VH MCS5

2

24

24

24

HT MCS14/VHT MCS6

2

23

23

23

HT MCS15/VHT MCS7

2

22

22

22

VHT MCS8

2

22

22

22

VHT MCS9

2

-

21

21

Note: The maximum power setting will vary according to individual country regulations and antenna gain. Refer to the product documentation for specific details.

Interfaces

Uplink options

Ethernet, SFP, and wireless mesh

Antennas

Dual band

2.4-GHz peak gain (dBi)

5-GHz peak gain (dBi)

Antenna type

AIR-ANT2547V-N

AIR-ANT2547VG-N

AIR-ANT2547V-N-HZ

4

7

Omnidirectional

AIR-ANT2568VG-N

6

8

Omnidirectional

AIR-ANT2588P3M-N=

8

8

Directional, dual polarization, 3 port

AIR-ANT2513P4M-N=

13

13

Directional, dual polarization, 4 port

2.4-GHz single band

Peak gain (dBi)

Pattern

AIR-ANT2450V-N=

AIR-ANT2450VG-N=

5

Omnidirectional, vertical polarization

AIR-ANT2450HG-N=

5

Omnidirectional, horizontal polarization

AIR-ANT2480V-N=

8

Omnidirectional

AIR-ANT2413P2M-N=

13

Directional, dual polarization, 2 port

5-GHz single band

Peak gain (dBi)

Pattern

AIR-ANT5150VG-N=

5

Omnidirectional, vertical polarization

AIR-ANT5150HG-N=

5

Omnidirectional, horizontal polarization

AIR-ANT5180V-N=

8

Omnidirectional

AIR-ANT5114P2M-N=

13

Directional, dual polarization, 2-port

Note: For antenna details refer to the Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide.

RF ports

4x MMCX female

Power input

Power consumption

Compliance

Information technology equipment:

UL/CSA 60950-1

UL/CSA 62368-1

IEC/EN 60950-1

IEC/EN 62368-1

CB report and certificate to IEC 60950-1 with all country deviations

CB report and certificate to IEC 62368-1 with all country deviations

Immunity

Emissions

Radio approvals

◦      FCC (Americas, parts of Asia, and the Middle East)

◦      ETSI (Europe, Middle East, Africa, and parts of Asia)

◦      TELEC (Japan)

◦      KCC (Korea)

Radio EMC

Security

◦      X.509 digital certificates

◦      MAC address authentication

◦      Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)

◦      802.11i, Wi-Fi Protected Access (WPA2), WPA

◦      802.1X authentication, including Extensible Authentication Protocol and Protected EAP (EAP-PEAP), EAP Transport Layer Security (EAP-TLS), EAP-Tunneled TLS (EAP-TTLS), EAP-Subscriber Identity Module (EAP-SIM), and Cisco Lightweight Extensible Authentication Protocol (LEAP)

◦      Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)

◦      VPN pass-through

◦      IP Security (IPsec)

◦      Layer 2 Tunneling Protocol (L2TP)

PoE output

35.3 W total

Maximum 30W per PSE port

USB interface

USB 2.0 / USB 3.0 supported

Dimensions (H x W x L)

8.5 in. x 7.55 in. x 1.9 in.

Weight

3.1 lbs.

Environmental (operating temperature range)

Mounting options

DIN rail

Warranty

1 year
